P2-32SIndoor LED main technical parameters（die-casting aluminum）
|
|
Physical
point Spacing 2mm
|
United
board size 128X128㎜
|
Unit
box size 512×5120×68㎜
|
|
Physical
density 250000 point/㎡
|
Luminous
color 1R1G1B
|
Unit
borad resolution 64*64=4096 DOTS
|
|
Unit plate weight 0.14㎏
|
|
Box Resolution 256*256
|
Box
area 0.262144m²
|
Die-Cast
Aluminum box weight 7.18KG±0.05KG
|
|
Main technical parameters
|
|
Best
viewing distance 2m～27m
|
Visual
angle level≧160°optional
|
vertical≥120°optional
|
|
Average
power cinsuption ＜500W/㎡
|
Max
power dissipation＜1000w/㎡
|
Control
method：synchrocontrol
|
|
DVI graphics card
|
Driving
mode 1/32scan
|
Repetition
frequency ≧20w
|
|
Refresh frequency ≧1920Hz
|
White
balance brightness ≧1000cd/㎡
|
Frame-changing
frenquency ≧500hz
|
|
Brightness Adjustment
|
Automatic
adjustment of luminance induction
|
Class
16 adjustment
|
|
Software manual adjustment：calss 100 adjustable 100
|
|
Computer operating system
|
|
WIN98、WINXP、WIN2000,etc
|
|
Video signal
|
|
RF、S-Video、RGB、RGBHV、YUV、YC、COMPOSITION,etc
|
|
cintrol system
|
|
PCTV
card（optional）+DVI graphics card+master cintrol
card+optical fibre transmission（optional）
|
|
MTTF ≧5000
hours
|
Life
span 75000～100000 hours
|
Pixel
runaway rate ＜0.0002
piece
|
|
Project classification PH6-8S
|
Encapsulation
form Traid
|
LED
Encapsulation mode 1515
|
1.Wide application field & short ROI time:
commercial advertising LED display screen, Stadium perimeter LED display screen, Mobile trailer LED display screen for mobile media, shopping mall LED display screen for logo showing, bank&stock exchange LED display screen for rates showing, train & bus station LED display screen, air port LED display screen, telecommunication LED display screen system for information showing and instruction
2. High Contrast ratio: 4000:1
Which is a very high level to ensure a vivid image of our LED display screen system.
3. Clear vivid image quality:
Even in direct, full-on sunlight to ensure you attract more audience to get short ROI of your LED display screen's investment.
4. Long-term Brightness:
7000-nit brightness (for outdoor full color)(2000 nits brightness for indoor full color ) capacity throughout product lifetime of the LED display screen.
5. Easy Installation & Using:
easy & simple installation interface and user friendly software to ensure the user friendly interface of the LED display screen system
6. Convenient Servicing:
Front and rear cabinet access makes the maintenance work very convenient and low cost to help you concentrate more time and energy on your main marketing promotion business.
