Performance Parameters

Scan Engine:

650nm laser scan engine (one-dimensional)

Processor:

32-bit ARM processor

Operating System:

uCOS II

Memory:

512 MB FLASH

Display:

2-inch color LCD screen

Tip:

standard buzzer, LED lights

Keyboard:

24 keys keyboard

System Interface:

USB keyboard, USB virtual serial port

Wireless Module:

433MHz radio channel

Communication distance:

150 meters (indoor) 400 meters (outdoors)

Scanning Parameters

Scan speed:

100 ± 10 times / sec.

Scan Depth:

5mil: 35-100mm; 15mil: 30-300mm; 30mil: 40-500mm

Resolution:

0.1mm (4mil)

Decoding type:

EAN-8, UPC-E, EAN13, UPC-A, Code39 code, cross 25 yards, UCC / EAN 128, Code128 code, CODE BAR, MSI PLESSEY, industrial 25 yards, 11 yards, Code93 code

Electrical Parameters

Current:

270mA standby 28mA when scanning

Power Source:

USB Charging

Battery:

1.2V, two AA 2600mAH NiMH batteries

Standby Time:

100 ~ 150 hours

Working Hours:

8 to 10 hours

Charging Time:

more than 8 hours

Mechanical Parameters

Size:

170mm (L) × 70mm (W) × 36mm (H)

Housing Material:

ABS

Weight:

255g (with battery)

Communication Interface:

USB

Environmental Parameters

Working Temperature:

-10 ℃ ~ 40 ℃

Storage Temperature:

-20 ℃ ~ 50 ℃

Humidity:

10% ~ 95%

Ambient Light:

0 ~ 70,000 lux

Accessories

Data cable

Application Scenarios

Store, Shopmall, Warehouse management, Production line management, Library management, The apparel industry, FMCG, retail, Supply chain and other industries, The logistics industry (including warehousing, Ccourier, LTL transportation and other materials), Manufacturing, Fixed assets, Medical industry
