Embedded Contact Smart Card Reader Module DC1701

Embedded Contact Smart Card Reader Module DC1701

DC 1701 is a contact smart card reader module that is quickly and easily embedded into integrated systems, such as vending machines, kiosks, and so forth.

Product Name- Embedded Contact Smart Card Reader Module DC1701

Product Description-

The DC1701 Contact Card Reader Module is designed for fast and easy integration into embedded systems. It is compliant with ISO7816. Moreover, with low power consumption feature, it supports to be integrated low power consumption system, such as POS terminal, phone with PSTN link power.


Support full-size smart card reader/writer.

ISO7810 ID-1 non-capture card slot

Read/write cards with ISO 7816 compliant with class A ( 5V)

T=0 or T=1 protocol

Minimum 200 000 card insertion cycles

UART interface


Baud rate: 115200 bps

Ultra Low Power Consumption

Maximum operating current: 15 mA

Support power down or sleep mode

Product Applications-

Transport operators,  retails

unattended applications in vending machines, parking meters and gaming kiosks

ID verification
