Non Noisy imported linear rail and Italian belt

Rear feeding and takeup system with air swelling shaft, 1000m transfer paper printing design

Multiple calibration technique print body

High resolution Aluminum Alloy ink stack

Technical parameters

Print Head Quantily

Epson 4720 3 Pcs

Printing width

1.82m X (Unlimited Length)

Printing Thickness

≤5mm

Printing Speed

Printing Mode

3 H

Epson 4720

2pass

120㎡/h

3pass

90㎡/h

4pass

65㎡/h

Ink

Eco-solvent ink/Water based ink/Sublimation Ink C·M·Y·K

Media Type

Textile materials  Digital transfer paper

Image Format

TIFF/JPG/EPS/PDF

RIP Software

Maintop(Standard)/Photoprint(Optional)/WASATCH

Computer Configuration

System : windows7/8/10 64bits(Professional/Version)CPU:≥Inter i5 RAM : 8GB Hard Disk : SATA 500G Hard Disk Format : NTFS CD Rom : DVD Recordable Space for Disk C : 100GB at least

Power Supply

AC 200V,50HZ±10%,UPS is required

Operation Environment

Temperature 20~30℃   Humidity 60~70℃

Power

4000W

G.W./N.W.

460kg/340kg

Packing Size/APP Size

L/W/H 3300mm*950mm*100mm/3200mm*860mm*950mm
