FS1003 Fuel Water Separator Spin-on with Drain, Sensor Port and Reusable Sensor
Cross Reference :
CUMMINS 34068894, Baldwin BF1293-SPS, Donaldson P551103
The FS1003 Parameter:
|
Part Number
|
FS1003
|
|
Parts Name
|
Fuel Water Separator
|
|
Brand
|
Fleetguard
|
|
Overall Height
|
248.67 mm
|
|
Largest OD
|
93.73 mm
|
|
Gasket OD
|
71.88 mm
|
|
Gasket ID
|
62.48 mm
|
|
Thread Size
|
1-14 UNS-2B
|
|
EMULSIFIED WATER SEPARATION
|
95 % (95 %)
|
|
FREE WATER SEPARATION
|
95 % (95 %)
|
|
EFFICIENCY, TWA BY SAE J 1985
|
98.7 % (98.7 %)
|
|
MICRON RATING BY SAE J 1985
|
10 micron (10 micron)
|
The FS1003 Details:
Notes:CAUTION: Furnished O-Ring must be installed on post for seal.
Contains:Sensor Port Thread: M14 x 2.0;Standpipe
TheFuel Water Separator Spin-on FS1003 with Drain, Sensor Port and Reusable Sensor.
