Overview

Finisar’s FTLF8526P3BNL SFP+ transceivers are designed for use in wireless application of links up to 6.1 Gb/s data rates over multimode fiber. The optical transceivers are compliant per the RoHS Directive 2011/65/EU.

Brand Name:  Huawei

Product Number:  FTLF8526P3BNL

Discription: Fiber Optic Transceiver Module Wireless 6.1Gbps 850nm 3.3V LC Duplex Pluggable, SFP+ from Finisar (6G-850nm-120m-MM-SFP+)

Product Features 

• Up to 6.1 Gb/s bi-directional data links 
• Hot-pluggable SFP+ footprint 
• Built-in digital diagnostic functions 
• 850nm Oxide VCSEL laser transmitter 
• Duplex LC connector 
• RoHS compliant and Lead Free 
• 300m on high-bandwidth 50/125um (OM3) MMF 
• Metal enclosure, for lower EMI 
• Single 3.3V power supply 
• < 0.5W power dissipation 
• Extended operating temperature range: -40°C to 85°C

Applications

Wireless – CPRI, OBSAI, LTE
