Factory Wholesale Corrugated Carton Flexo Printing Machine
Flexo Printing Machine for Corrugated Cardboard Features：
·This machine is designed and made to high quality and safety standard,with the advantages of high speed, auto control and quick order shift.
·Computerized control,order setting in touch screen.
·The Folding Section adopts belt transfer system assisted with vacuum suction,to make best transfering and folding quality.
·The Gluing Section adopts U.S.A VALCO high speed auto-sensor glue spray system.
·The correction device in the Countering Section can conquer the fish-tail,makes the carton even.
·The quantity of bundle come out from the Counter Ejector can be set in touch screen.
·Able to shift order of the idle Printing Section under production.
·All electronic and pneumatic components are with European standards.
Flexo Printing Machine for Corrugated Boxes Specification：
Data/Model
|
900x2000
|
900x2400
|
1200x2000
|
1200x2400
|
Printing Speed(m/min)
|
200
|
200
|
200
|
200
|
Max Machine Speed(pcs/min)
|
350
|
300
|
250
|
250
|
Max Feeding Size(mm)
|
880x2000
|
880x2400
|
1180x2000
|
1180x2400
|
Min Feeding Size(mm)
|
280x640
|
280x640
|
320x700
|
320x700
|
Skip Feeding(mm)
|
1100x2000
|
1100x2400
|
1500x2000
|
1500x2400
|
Max Printing Area(mm)
|
800x2000
|
800x2400
|
1150x2000
|
1500x2400
|
Thickness of Printing Plate(mm)
|
7.2
|
7.2
|
7.2
|
7.2
|
Min Panel(mm) Slot Type L.
|
240x80x240x80
|
240x80x240x80
|
260x90x260x90
|
260x90x260x90
|
Max Slotting Depth(mm)
|
250
|
250
|
320
|
320
|
|
Min Folding Size(mm)
|
280x760
|
280x760
|
320x800
|
320x800
|
Max Thickness of Sheet(mm)
|
8
|
8
|
12
|
12
|
Dimension(LxWxH)
T
F
|
T:18832x4750x2800
F:19552x4750x2800
|
T:18832x5150x2800
F:19550x5150x2800
|
T:20255x4870x2800
F:20975x4870x2800
|
T:20255x5270x2800
F:20975x5270x2800
|
Our Research and Development:
KESHENGLONG has a perfect Research and Development system, and owns a high level R&D team, leading capability of independent innovation, and complete producing, processing and manufacturing capability. We has Full computer gantry boring and milling machining center, CNC pentahedron boring and milling machine, 5 meter grinding machine etc., more than 200 set of processing equipment.
