1.Technical parameters
Test Method: Method A or Method B(optional)
Test range: Method A 50~2000g; Method B 300~2000g
Test precision: 1g
Test environment: 23℃ 50%RH
Sample size（Φ）: 180mm
Power supply: AC 220V 50Hz
Weight: 70kg
Dimensions: 650mm*650mm*(2200 to 2600)mm
2. Main components
LCD screen terminal,air cylinder,printer
3. Product features
LCD display test data.
Easy operation, auto process data.
Pneumatic clips.Automatically clip and release dart.
Built-in printer can print report.
Two test methods: Method A and Method B.
Meet the national and international standard.
Intelligentize test procedure,greatly improving work efficiency.
4.Standards
The instrument is up to standards of Q/GBPI 03-2017
