ESS311203-3LCD20
GE-100FX Spring-Latch SFP Transceiver, 20KM Reach
Features
Ø Double LC type pluggable optical interface
Ø 1310nm FP laser transmitter and PIN receiver
Ø Up to 20km on 9/125µm SMF
Ø Hot-pluggable SFP footprint
Ø Low power consumption<1W typical
Ø The metal shell shielding electromagnetic interference
Ø RoHS compliant and lead-free
Ø Single +3.3V power supply
Ø Built-in PHY supporting SGMII Interface
Ø 100 BASE-LX operation
Ø Ambient operating temperature: 0 to +70°C
Applications
Ø Switch to Switch interface
Ø Switched backplane applications
Ø Router/Server interface
Ø Other optical transmission systems
Ordering information
Product part Number
|
Data Rate
(Mbps)
|
Media
|
Wavelength
(nm)
|
Transmission
Distance(km)
|
PHY IC
|
ESS311203-3LC(D)201
|
125
|
SMF
|
1310
|
20
|
Marvell
|
ESS311203-3LC(D)202
|
125
|
SMF
|
1310
|
20
|
Broadcom
|
Description
ETU-LINK’s GEFE Small Form Factor Pluggable (SFP) transceivers are compatible with the Small Form Factor Pluggable Multi-Sourcing Agreement (MSA), and are designed for SGMII MAC interface to 100BASE-LX (The SGMII MAC Interface implements a modified 1000BASE-X Auto-Negotiation to indicate link, duplex, and peed to the MAC). The transceiver consists of four sections: the standard SFP part, the PHY part build with SGMII interface, the 1310nm FP laser and the PIN photo-detector. The module data link up to 20km in 9/125um single mode fiber.
