GE Fanuc IC695RMX128 PACSystems RX3i Redundancy memory Exchange module that is manufactured by Emerson Automation

This module has a user memory of 128MB SDRAM and supports operating as a reflective memory network or as a dedicated link between Redundant configured RX3i CPUs.



Product description

When used in a redundant CPU configuration, the IC695RMX128 reflects the contents of the IC695CMX128. With a reflective memory link, any update on one node is reflected and updated to every other nodes connected to the same network. Connection is established via a fiber-optic network and supports connection of up to 256 nodes.

This module comes with 128 MB of reflective memory with a fiber optic power that requires LC type connector, designed for transmission speed of up to 2.12 Gbaud. This module operates when supplied with 580 mA @ 3.3 VDC and 220 MA @ 5 VDC.

The IC695RMX128 is used in redundancy systems, it cannot be utilized to perform general purpose memory Xchange capabilities. Additionally, a complete communication path must be established to complete the memory Xchange network. A complete communication path consists of a primary RMX unit and a corresponding secondary RMX unit. Two (2) high-speed fiber-optic cables must be connected to the RMX pair and must form a 2-node ring. Since a dedicated RMX module must be used for redundant controller configuration, no other RMX or reflective nide must be used for any redundant controller design. Configuration of RMX node(s) is doe via the programming software, not by jumper or DIP switch settings. This ensure centralized modification of the module and minimizes hardware interruption.



The GE Fanuc Automation IC695RMX128 redundancy memory module can be connected to other devices through fiber-optic cables in a daisy-chain loop. The transmission is performed from node to node until it reaches the final receiver. This module comes with a reflective memory of 128 KB and a high-speed and easy-to-use 2.12 GBaud fiber-optic network. This module occupies a single slot in the RX3i rack. The GE Fanuc Automation IC695RMX128 redundancy memory change module has a zirconium ceramic ferrule, an insertion loss rating of 0.35 dB maximum, and a return loss. The input power of this module is 580 milliamps at 3.3 Volts DC and it is 220 milliamps at 5 Volts DC. This module can be inserted in an easily and with the power to the system still on. This insertion mode is called jot insertion and applies to certain parts from the RX3i PacSystems series.

Packing & Delivery

1)100% brand New and Original Factory Seal!

2)Warranty: 1 year

3)Package: Original packing with cartons.

4)Delivery time: Shipped in 3-7 days after payment

5) All the goods will be tested before shipment.

Our Services

1  All our products are new and original, and of good quality.

2  Our prices are very competitive.

3  We have a large quantity in stock, so we could help the customers to get the components which are difficult to get.

4  All inquiries will be valued and will reply in 24 hours.

5  Fast shipping, and good after-sale service
