Product description

The CPU 772 is a single slot PLC CPU which allows floating point calculations. The CPU 772 is programmed and configured by MS-DOS or WIndows based programming software to perform real time control of machines, processes and material handling systems. The CPU 772 communicates with I/O and smart option modules over the rack mounted backplane (IC697CHS750, 782, 783, 790, 791) by way of the VME C.1 Standard format. Supported option modules include IC697 LAN interface modules, several Coprocessor modules, Bus Controller for IC660/IC661 I/O products, Communications modules, I/O Link Interface, and all of the IC697 family of discrete and analog I/O modules (see the applicable

Program and data memory for the CPU 772 is available by attachment of an expansion memory board with either 64, 128, 256 or 512 Kbytes of battery-backed CMOS RAM. Operation of this module may be controlled by the three position switch or remotely by an attached programmer and programming software. CPU status is indicated by three green LEDs on the front of the module.

Our Services

1  All our products are new and original, and of good quality.

2  Our prices are very competitive.

3  We have a large quantity in stock, so we could help the customers to get the components which are difficult to get.

4  All inquiries will be valued and will reply in 24 hours.

5  Fast shipping, and good after-sale service

Other series:  IC200/IC693/IC694/IC695/IC697/IC698/ IS200/IS215/Relay module
