GE IC695CHS016 Universal Backplane

Features

The RX3i Universal Backplane supports both PCI-based (IC695) and serial (IC694) I/O and option modules with its  dual-bus backplane. The RX3i Universal Backplane also supports 90-30 IO and option modules.  See the  PACSystems RX3i System Manual, GFK-2314 for lists of supported modules.

  ▪ Terminal Strip on the left end for Isolated +24V input

  ▪ Backplane grounding point

  ▪ An integral grounding bar for connecting module/shield grounds

  ▪ Serial Expansion connector for connection to Serial Expansion and Remote Backplanes

  ▪ Slot numbers printed on the backplane that can be used as a reference for configuration.

Applications

• Signal path isolation

• Ground loop elimination

• Data acquisition

• Industrial control and instrumentatio

Description

The GE Fanuc IC695CHS016 backplane is a universal backplane from the GE RX3i PACSystems series.

It is a dual-bus universal backplane that is made to accommodate option modules, serial I/O modules, and PCI-based I/O modules.

The IC695CHS016 universal backplane is made to be mounted horizontally on a rack in a GE RX3i PACSystems PLC. It needs about 4 inches or 102 millimeters of clearance around it on all sides so that it and the modules that it hosts can dissipate heat properly and experience air-cooling.

The IC695CHS016 universal backplane comes with 16 slots and its dimensions are 5.6 inches x 23.7 inches x 5.8 inches in height, length, and depth, respectively.
