Customized ISUZU GIGA Water Transport Tanker Vehicle
Introduction
GIGA Water Delivery Tanker ISUZU (also
called ISUZU GIGA Water hauling truck, GlGA clean water truck, Water
spray vehicle, Water transportation truck, Water tank lorry Isuzu GIGA) is
produced for transportation and distrubition of industrial and drinking
water, spraying and washing of streets and tunnels, dust and
environmental control and fire-fighting purposes. In order to achieve
those different operations , each water tanker truck is equipped with
various features and itās designed according to capacity of the carrier
vehicle.
Advantages
|
|
100% custom-made
|
|
|
3 cbm to 22 cbm available
|
|
|
Short delivery time 7~30 days
|
|
|
Easy operation & Easy maintenance
|
|
|
15 years spare parts & Technical support
|
Main Parameters
|
Manufacturer
|
PowerStar Trucks Industry Co., Limited
|
|
Product Name
|
ISUZU GIGA Refuse Compactor Trucks
|
|
Vehicle Brand Series
|
ISUZU
|
|
Vehicle Model
|
PST5210GSS
|
|
Production Time
|
25 days
|
|
Chassis parameters
|
Overall dimensions
|
mm
|
9260*2500*2960
|
|
Gross weight
|
kg
|
21,000
|
|
Kerb weight
|
7,760
|
|
Wheelbase
|
mm
|
4,500
|
|
Driving type
|
4*2
|
|
Chassis model
|
ISUZU GIGA Heavy-duty
|
|
Tire size
|
10.00-20-16PR
|
|
Number of Tires
|
6+1
|
|
Passengers in cab
|
3
|
|
Engine
|
Engine model
|
6UZ1-TCG50
|
|
Type of fuel
|
Diesel
|
|
Power
|
380HP
|
|
Max speed
|
Km/h
|
95
|
|
Emission standard
|
EURO 4,5,6
|
|
Water Tanker performance
|
Tanker Body
|
14,000L
|
|
Body Material
|
Weather Resisting Steel
|
|
Tanker Shape
|
Ellipse as standard
|
|
Water Pump
|
China Famous Brand 50m3/h
|
|
Optional Italy, Euro brand
|
|
Washing Width
|
ā„20 M
|
|
Washing Speed
|
5~20 km/h
|
|
Rear Cannon Range
|
ā„50 M
|
|
Spray Bar
|
Front, Side & Rear
|
|
Hose & Hose-carrier
|
Factory standard
|
|
Control Panel
|
English
|
|
Walkway and Hand rail
|
Yes
|
|
Painting
|
Two primers, and one final paint coating
|
|
Color & LOGO
|
According to wish
|
|
Factory standard
|
āUā shape
Sub Frame, Hydraulic system, Ejector panel, Safety protection, Rotating Lamp,
Working Lamp, Hand holds, Mudguards and rubber flaps...
|
|
Documents
|
English
operation manual, Spare parts list, and all necessary export docs.
|
|
Optional equipment
|
1, Stainless steel tank, Aluminum alloy tank
2, Wider platform and Fire Cannon
3, Electricity controlled separately sprinkler
4, Spreading salt water * Snow-melting agent
|
