GLC-SX-MMD Overview
The GLC-SX-MMD 1000BASE-SX SFP is made for Multimode Fiber only.
The 1000BASE-SX SFP, compatible with the IEEE 802.3z 1000BASE-SX standard, operates on legacy 50 μm multimode fiber links up to 550 m and on 62.5 μm Fiber Distributed Data Interface (FDDI)-grade multimode fibers up to 220 m. It can support up to 1km over laser-optimized 50 μm multimode fiber cable. 850-nm wavelength, extended operating temperature range and DOM support, dual LC/PC connector.
GLC-SX-MMD Specification
|
Brand
|
Cisco
|
|
Part
number
|
GLC-SX-MMD
|
|
Product
Description
|
1000BASE-SX SFP transceiver module. MMF.
850nm. DOM
|
|
Wavelength
|
850
|
|
Fiber
Type
|
MMF
|
|
Core
Size (μm)
|
62.5
|
|
50
|
|
50
|
|
50
|
|
Modal
Bandwidth
|
160
|
|
200
|
|
400
|
|
500
|
|
2000
|
|
Operating
Distance
|
220 (722 ft)
|
|
|
275 (902 ft)
|
|
|
500 (1,640 ft)
|
|
|
550 (1,804 ft)
|
|
|
1000 (3281 ft)
|
|
Warranty
|
One year
|
|
Lead
time
|
2-3 business days
|
|
Shipment
|
DHL, Fedex, Aramex, EMS or per
request
|
