4G part
FreqRange:
700-960/1710-2700MHz
Gain:2dBi
Impedance:50Ω
Polarization:vertical
GPS part
Center frequence:1575.42 MHz
LNA
Gain:38±2 dB
Noise
Figure:1.5 dB
Filter
Out Band Attenuation:12dB Min f0+50MHz
16dB Min f0-50MHz
DC Voltage:2.2~5 V / 3~5 V
DC Current:5~15 mA / 6~12 mA
|
