GPS Antenna:
DielectricAntenna:Center Frequency:1575.42±1MHz
Band Width:CF±5MHz
Polarization:RHCP
Gain:5dBic（Zenith）
V.S.W.R:＜1.5
Impendance:50Ω
Axial Ratio:3dB（max）
LNA:Gain:28±2dB
Noise Figure:＜1.5
Ex-band Attenuation:12dB@CF+50MHz/16dB@CF-50MHz
V.S.W.R:＜2.0
Supply Voltage:2.2~5V DC
Current Consumption:5~15mA
GSM Antenna:
Frequency Range:824~960MHz/1710~2170MHz
V.S.W.R（min）:＜2.5
Polarization:Linear
Gain:2dBi
Impendance:50Ω
