Green Roof Materials Hdpe Drain Plates

As the raw material, HDPE ensure products all the best function. HDPE Green Roof Materials and Drain Plates brought a leading global new design concept, that is, through professional waterproof design, professional guide water planning and comprehensive protection, to achieve the overall protection system security goals.


  • Press Strength695KN
  • Total Volume0.06m3/bundle
  • Size410x200x25mm
  • ColorBlock
  • MaterialHDPE

Green Roof Materials Hdpe Drain Plates Specifications:

 Item No.  SB-25A  SB-25B  SB-25C
 Color  Light green  Dark green  Black
 Picture  Green Roof Materials Hdpe Drain Plates  Green Roof Materials Hdpe Drain Plates  Green Roof Materials Hdpe Drain Plates
 Size(mm)  410x200x25  410x200x25  410x200x25
 Unit weight(g/m2)  3150g/m2  3150g/m2  3150g/m2
 Material  HDPE  HDPE  HDPE
 Pressure strength(Kpa)  855KN  745KN  695KN
 Hardness  135  113  92
 Water Drainage  90%  90%  90%
 Vertical Circulating  Capacity(cm3/s)  25cm3/S  25cm3/S  25cm3/S
 Water retention(L/m2)  2.6L/m2  2.6L/m2  2.6L/m2
 Loading Capacity

 1100SQM=1x20FT CONTAINER

 2233SQM=1x40FT CONTAINER

 2533SQM=1x40FT CONTAINER

 1100SQM=1x20FT CONTAINER

 2233SQM=1x40FT CONTAINER

 2533SQM=1x40FT CONTAINER

 1100SQM=1x20FT CONTAINER

 2233SQM=1x40FT CONTAINER

 2533SQM=1x40FT CONTAINER

 Package  18pcs/bundle,0.06m3/bundle  18pcs/bundle,0.06m3/bundle

 18pcs/bundle,0.06m3/bundle

 MOQ  1x20FT CONTAINER  1x20FT CONTAINER  1x20FT CONTAINER

Drainage Plate

LEIYUAN Hdpe Drain Plates to replace the drainage layer pebbles treatment not only save time,effort and energy, saving investment, but also reduce the load of the building. Good Drainage system for normal use and life cycle of civil construction and the building has an important role. Long and short cylindrical Green Roof Materials and geotextiles to form a drainage system, to form a water seepage, water and drainage systems.



Drain Plates light of its own weight, the roof structure will not increase the load. 100% recycled, not cause secondary pollution to the environment. Loading capacity per square can reach 80 tons weight, suitable for create a variety of landscape.

Drainage Plate

Strength Drainage Plate Application:

Roof greening

Bridge abutments

Underground

Tunnels

Play ground

Retaining walls

Golf courses water drainage

Fire truck access paths

Golf buggy

Trolley paths

Modern factory building

Noble living communities

Emergency vehicle access roads through fields


Drainage Plate

Features and Benefits:

Lightweight

High compression strength

Seepage proof

Available in different sizes

Cost save

Water drainage and storage

Easy installation

No surface drains required

Reduces surface temperature around building

High load bearing 148.58t/m2 unconfined

Replenishes water supply to landscaped areas

Unique and easy to use interlocking system

Promotes fast and excellent plant growth

Strong structure can support heavy loads

Retains a minimum of approximately 76L/m2 of perched water above the cells

Drainage Plate

Strength Drainage Plate Construction:

Hdpe Drain Plates

Drainage Plate

Strength Drainage Plate Projects View:

Green Roof Materials

Leiyuan Strength Drainage Plate: Good water feature, Long life service!
