Heat Treated Fire Resistant Sleeve For Hoses & Cable

IFRS Heat Treated Fire Resistant Sleeve For Hoses & Cable is a special heat cleaned fire sleeve, made by special heat treated fiberglass braided coated with silicone rubber. It is standard fire sleeve used to protect hoses, wires, lines, cables.



Description:

IFRS heat treated fire resistant sleeve for hoses & cables is made by special treated fiberglass braided sleeve coated with heavy silicone rubber, the fiberglass is after heat cleaned and get special tan colored. Heat treated to removed starches, oils and other impurities that naturally occur in glass.


Features:

It offers excellent short term flame protection and great insulation properties for high temperature.
Resistant to hydraulic fluids, oils and fuels and can protects against molten splash and flames.


Application:

It’s mainly used in steelworks, glass and ceramic industry, in railway and some other fields.
Used to protect fuel lines, hydraulic and oil lines from heat and to prolong the life of wiring and hoses in case of fire so that critical systems can function longer.

Specifications:

Part Number Normal Inside diameter Meter for spool
Inches mm Dash # Meter
IFRS-6 1/4 6 -4 20
IFRS-8 5/16 8 -5 20
IFRS-10 3/8 10 -6 20
IFRS-11 7/16 11 -7 20
IFRS-13 1/2 13 -8 20
IFRS-16 5/8 16 -10 20
IFRS-19 3/4 19 -12 20
IFRS-22 7/8 22 -14 20
IFRS-25 1 25 -16 20
IFRS-29 1 1/8 29 -18 20
IFRS-32 1 1/4 32 -20 20
IFRS-35 1 3/8 35 -22 20
IFRS-38 1 1/2 38 -24 20
IFRS-41 1 5/8 41 -26 20
IFRS-44 1 3/4 44 -28 20
IFRS-48 1 7/8 48 -30 20
IFRS-51 2 51 -32 20
IFRS-57 2 1/4 57 36 20
IFRS-60 2 2/5 60 -38 20
IFRS-64 2 1/2 64 -40 20
IFRS-67 2 5/8 67 -42 20
IFRS-70 2 3/4 70 -44 20
IFRS-73 2 7/8 73 -46 20
IFRS-76 3 76 -48 20
IFRS-83 3 1/4 83 -52 20
IFRS-89 3 1/2 89 -56 20
IFRS-95 3 3/4 95 -60 20
IFRS-102 4 102 -64 20
IFRS-114 4 1/2 114 -72 20
IFRS-121 4 3/4 121 -76 20
IFRS-127 5 127 -80 20
IFRS-152 6 152 -96 20


Technical Datasheet
Material Silicone, fiberglass
Working temperature -40 - +260
Flammability VW-1
Melting point +1650
Standard Color Iron oxide red
MOQ 20 meter each size
Cutting tool Scissors

Notes:
The part NO. will be followed by BK for black color, GR for gray color, OR for orange color, BL for blue color.
Special thickness upon request
Special length or packing upon request.
Customs LOGO upon request.


Image:

Heat & Fire Resistant Sleeves

Firesleeve for High Temp Hose & Cable ProtectionPyro-Jacket Silicone Sleeving
