Heavy duty aluminum square smart truss

this heavy duty aluminum truss is a standard truss suitable for 16m up projects




Truss Description:

Chaodastage has developed a broad range of trusses and a unique system to connect them, Spigot connection truss, we are
designed to make them suitable for a variety of applications, from a simple led screen truss or exhibition booth to big stage
truss structures prepared for high loading.

Chaodastage truss in different sizes, length and shapes, including straight lengths, corners and curves; all designed and
manufactured according to European standard EN13814 and welding EN1090 , we give you loading date, user manual and
video to teach you how to use these truss.

Truss Advantages:

1. Spigot connection way, easily and quickly installation

2. Make sure delivery time

3. Cooperate with supplier over 5 years, keep quality stable

4. Aluminum material report by SGS

5. TUV & CE certificate

6. Factory audited by SGS

7. Get ISO 9001: 2008 quality manage system

What A Event Management !





product material size main tube brace tube Vice tube Shape length

Spigot aluminum truss

Aluminum Alloy 6061-T6/6082-T6
290*290mm 50*3mm 20*2mm 20*2mm
square/traingle/ladder/Arch

0.5-4m
350*350mm 50*3mm 25*2mm 25*2mm
390*390mm 50*3mm 25*2mm 25*2mm
400*400mm 50*3mm 50*2mm 25*2mm
400*500mm 50*3mm 50*2mm 25*2mm
400*600mm 50*3mm 50*2mm 25*2mm
450*450mm 50*3mm 50*2mm 25*2mm






Specification:

Aluminum Alloy 6061-T6/6082-T6

Main Tube

Vice Tube

Brace Tube

50x4mm/50x3mm

50x2/30x2mm

20x2/25x2/30x2mm

Tube size base on truss size or customer's request



Span(m) symmetrical load(kg) Deflection(mm) Centre Load(kg) Deflection(mm)
2 1800 10 1300 10
3 1500 25 1060 20
4 1200 40 880 30
5 880 55 620 40
6 750 65 380 65
8 510 80 195 85
10 410 95 120 95
12 210 110 95 105


Chaoda has developed a broad range of trusses and a unique system to connect them, Spigot connection truss, we are designed to make them suitable for a variety of applications, from a simple led screen truss or exhibition booth to big stage truss structures prepared for high loading.

Chaoda truss in different sizes, length and shapes, including straight lengths, corners and curves; all designed and manufactured according to European standard EN13814 and welding EN1090 , we give you loading date, user manual and video to teach you how to use these truss .


Installation:


Test report:





Packing and shipping:


Factory:




FAQ:

1Q: What certificate do Chaoda Truss have?

     A: SGS and TUV certification.

2. Q: What is the terms of payment?

     A: We accept Western Union, by T/T, 30% of invoice value as deposit, 70% balance paid before shipment, and some others.

3. Q: Where is the loading port?

     A: Port Huangpu in Guangzhou or Ports in Shenzhen.

4Q: What is your packaging?

     A: Air bubble film or carton or flight case.

5Q: How long the deliver time?

     A: General it is about 5-15 days.

6Q: What is your after-sales service?

     A: Free parts provided once broken within one year.

7Q: Do Chaoda Truss accept OEM order?

     A: Yes, we welcome OEM order as well.

8Q: Do Chaoda Truss accept customized logo order?

     A: Yes, we can make logo on the truss for clients.
