Overview
Huawei GPON ONT HG8310M Optical Network Terminal
Huawei GPON ONT HG8310M optical network terminal (ONT) is a indoor optical network terminal in Huawei FTTx solution. By using GPON technology, ultra-broadband access is provided for home and SOHO users. The HG8310M provides one 10/100/1000M Base-T Ethernet port for connecting to a home gateway. The home gateway then can be connected to a PC, Mobile Terminal, STB, or Video phone to provide high-speed data, video services.
GPON ONT, 1*GE port
Without WiFi
Connector type SC/UPC
Coming with B+ or C+ Module
Can be configured by OLT or Web or NMS
Suitable for home and SOHO users
Packing dimension : 200*140*80mm
Gross Weight : 0.5kg
|
Specification
|
|
Working environment
|
-
Operating temperature: 0ºC to 40ºC
|
-
Environment humidity: 5% to 95% (noncondensing)
|
-
Pressure environment: 0 to 106 kPa
|
|
|
|
Power consumption
|
|
-
Maximum power consumption: 2.5 W
|
|
Power specifications
|
-
Power adapter input: 100 to 240 V AC, 50–60 Hz
|
-
System power supply: 11–14 VDC, 0.5 A
|
|
Security
|
|
|
Dimensions
(length x width x height)
|
|
|
Weight
|
|
