Specifications:
|
Model
|
P2.604
|
P2.976
|
P3.91
|
P4.81
|
|
Module size(mm)
|
250x250
|
250×250
|
250×250
|
250×250
|
|
Module resolution (dot)
|
90x90
|
84×84
|
64×64
|
52×52
|
|
Scanning
|
1/32S
|
1/28S
|
1/16S
|
1/13S
|
|
SMD
|
SMD1515
|
SMD2020
|
SMD2020
|
SMD2020
|
|
Maintenance
|
Front/Back
|
Front/Back
|
Front/Back
|
Front/Back
|
|
Installation
|
Hanging/streching
|
Hanging/streching
|
Hanging/streching
|
Hanging/streching
|
|
Cabinet size(mm)
|
500x500/500x1000mm
|
500×500/500×1000
|
500×500/500×1000
|
500×500/500×1000
|
|
Density(dot/m²)
|
147456
|
112896
|
65536
|
43264
|
|
Brightness(cd/m²)
|
≥600
|
800-1200/4500-6500
|
800-1200/4500-6500
|
800-1200/4500-6500
|
|
Max. Power Consumption（w）
|
800
|
800
|
800
|
800
|
|
Average Power Consumption（w）
|
400
|
400
|
400
|
400
|
|
Cabinet weight (kg)
|
7.5/12.5
|
7.5/12.5
|
7.5/12.5
|
7.5/12.5
|
|
Cabinet material
|
Die-casting aluminum
|
Die-casting aluminum
|
Die-casting aluminum
|
Die-casting aluminum
|
|
IP rate
|
IP31
|
IP31/IP65
|
IP31/IP65
|
IP31/IP65
|
|
Grayscale
|
10000:1
|
10000:1
|
10000:1
|
10000:1
|
|
Refresh rate(hz)
|
1920-3840
|
1920-3840
|
1920-3840
|
1920-3840
|
|
Frame change frequency
|
50/60hz
|
50/60hz
|
50/60hz
|
50/60hz
|
|
Horizontal viewing angle
|
>140°
|
>140°
|
>140°
|
>140°
|
|
Vertical viewing angle
|
>140°
|
>140°
|
>140°
|
>140°
|
|
Best viewing distance
|
>3m
|
>3m
|
>4m
|
>5m
|
|
Input Voltage
|
AC110V - AC220V
|
AC110V – AC220V
|
AC110V – AC220V
|
AC110V – AC220V
|
|
Module Max. current
|
5.0-7.0
|
5.0-7.0
|
6.0-7.5
|
5.5-7.0
|
|
Temperature-operating
|
﹣10℃～60℃
|
﹣10℃～60℃
|
﹣10℃～60℃
|
﹣10℃～60℃
|
|
Humidity-operating
|
10%～90%
|
10%～90%
|
10%～90%
|
10%～90%
|
|
Life span (H)
|
≥100,000
|
≥100,000
|
≥100,000
|
≥100,000
|
|
MTBF (H)
|
>10,000
|
>10,000
|
>10,000
|
>10,000
|
FAQ:
1. Can I buy samples and place an order?
-Can.
2. What is your delivery time?
-Depending on the order type and quantity, LED modules in stock will be shipped next day. Usually small quantities of customized products are shipped within 15 days, and large quantities are about 30 days.
3. How many years is your LED screen warranty?
Depending on the type of LED display screen with different configurations, a 1-5 year warranty is implemented
4. How is your digital HD LED advertising screen packaged?
Packing in carton, wooden box, air box
5. What are your payment terms?
- T/T, Western Union, MoneyGram, Paypal, start production with 50% deposit, and ship after full payment.
6. What is the shipping method?
Can be shipped by sea, air or express (EMS, UPS, DHL, TNT, FEDEX, etc.) Please confirm with us before placing an order.
7. How do you make our business long term and good relationship?
a. We keep good quality and competitive price to ensure our clients benefit;
b. We respect every customer, treat them as our friends, do business with them sincerely, make friends, no matter where they come from.
