High-Efficient Mono Crystalline Panel 60 cells 290w/295w/300w/305W/310W Intergrated with PERC Technology use for all type solar application system
Electrical Characteristics (STC)
|
Module Type
|
DHM60-290
|
DHM60-295
|
DHM60-300
|
DHM60-305
|
DHM60-310
|
|
Maximum Power (Pmax)
|
290W
|
295W
|
300W
|
305W
|
310W
|
|
Open-circuit Voltage (Voc)
|
39.5V
|
39.7V
|
39.9V
|
40.2V
|
40.4V
|
|
Maximum Power Voltage (Vmp)
|
32.2V
|
32.5V
|
32.6V
|
32.9V
|
33.1V
|
|
Short-circuit Current (Isc)
|
9.50A
|
9.55A
|
9.64A
|
9.74A
|
9.83A
|
|
Maximum Power Current (Imp)
|
9.01A
|
9.08A
|
9.20A
|
9.27A
|
9.37A
|
|
Module Efficiency(%)
|
17.74%
|
18.04%
|
18.35%
|
18.65%
|
18.96%
|
|
Power Tolerance
|
0~+5W
|
|
Standard Test Environment
|
Irradiance 1000W/m2, Cell Temperature 25℃，Spectrum AM 1.5
|
60cells Packing Details
|
Container
|
20GP
|
40GP
|
40HC
|
|
pcs/pallet
|
30
|
30
|
30
|
|
pallet/container
|
14
|
28
|
28
|
|
pcs/container
|
400
|
840
|
924
|
First-class solar panel warranty Reliable quality
1. 10 years material & technology guarantee
2. 25 years linear power output guarantee
3. 0-+5W Positive power output guarantee
4. 100% Double full EL inspection
Product Characteristics
· Excellent PID free performance.
· 5 busbar solar cell adopts new technology to improve the efficiency of mono solar panel , offers a better aesthetic appearance, making it perfect for rooftop installation
· Higher solar panel conversion efficiency(up to 18.65%) benefit from Passivated Emmiter Rear Contact (PERC) technology
· Advanced glass and solar cell surface texturing allow for excellent performance in low-light environments
· Certified to withstand: wind load (2400 Pascal) and snow load (5400 Pascal)
· Certified anti Salt-mist,anti ammonia corrosion performance,sand and storm test by TUV Rheinland and TUV Nord.
