Specification of aluminum nitride ceramic powders:
|
Part No.
|
Particle
|
Purity
(%)
|
SSA
(m2/g)
|
Bulk density
(g/cm3)
|
Density
(g/cm3)
|
Crystal
|
Color
|
|
NP1307-50N
|
50nm
|
99.5
|
70
|
0.15
|
3.5
|
Hexagonal
|
grey white
|
NP1307-100N
|
100nm
|
99.5
|
50
|
0.3
|
3.5
|
Hexagonal
|
grey white
|
NP1307-1U
|
1-3um
|
99.5
|
26
|
0.63
|
3.5
|
Hexagonal
|
grey white
|
Note: We can supply different size products of aluminum nitride ceramic powders according to client's requirements.
AlN (aluminum nitride) has excellent thermal conductivity, thermal expansion coefficient, good insulation, light transmittance, high temperature and corrosion resistance.
Application of aluminum nitride ceramic powders:
1. Aluminum nitride is an electrical insulator with good dielectric properties can be used on electrical components
2. Aluminum nitride is a great crucible material for semiconductor integrated circuit substrate, cast iron, aluminum and its alloys.
3. Aluminum nitride (AlN) with low temperature deposition of high-brightness LED is applied to optoelectronic engineering, including optical and electronic storage interface for matrix dielectric layer, a high thermal conductivity testimony chip carrier, as well as for military use
4. Aluminum Nitride also has the property of translucent, is used as fine ceramic auxiliary additives
SEM & XRD of aluminum nitride ceramic powders:
Storage conditions:
aluminum nitride ceramic powders should be sealed and stored in a dry and cool environment. It should not be exposed to the air for a long time, to prevent agglomeration due to moisture, affecting the dispersion performance and use effect, and should avoid heavy pressure, do not contact with oxidant, and transport according to ordinary goods.
