High Quality Beiben 6x4 truck dump Wth Cheap Price
1.shortest delivery time
2.more competitive price,
3.reliable and high efficient performance
4.good after-sales service
High Quality Beiben 6x4 truck dump Wth Cheap Price, we provide the most
competetive price for beiben 6*4 dump truck, our price for beiben 6*4
dump truck is the best price in china.
Product Description
SPECIFICATIONS FOR HIGH QUALITY BEIBEN DUMP TRUCK
|
Vehicle Specifications
|
Model
|
ND32602B34
|
Traction 4X2,6X4,8X4
|
6X4
|
Power
|
340HP
|
Weight Parameter
|
Complete Vehicle Kerb Mass(kg)
|
11970
|
Maximum authorized total mass (kg)
|
26000
|
Dimension Parameter
|
External Dimensions(mm)
|
Length (mm)
|
7169/7680
|
Width(mm)
|
2495/2500
|
Height(mm)
|
3180/3430
|
wheelbase(mm)
|
3450+1450
|
Internal cargo Sizes
|
Length (mm)
|
5200
|
Width (mm)
|
2300
|
Height (mm)
|
1500
|
Performance Parameter
|
Maximum Speed(km/h)
|
75
|
Maximum Grade ability(%)
|
35
|
Turning diameter(m)
|
16
|
Recommended Configuration
|
Engine
|
Engine Type
|
WD615.46
|
Rated power(kW)/Rev(r/min)
|
266/2200
|
Horse power
|
360HP
|
Torque(N*m)/Rev(r/min)
|
1800/1400-1600
|
Transmission
|
9JS180
|
Clutch(mm)
|
430
|
Gearbox
|
9 forward gears/ 2 reverse gears
|
Axle
|
Front Axle
|
BENZ-7.5
|
Rear Axle
|
BENZ-13
|
Axle load-bearing
|
Front axle
|
7500
|
|
Rear axle
|
13000
|
Fuel Tank(L)
|
400
|
Track(mm)
|
1995/1800/1800
|
Front overhang/rear overhang(mm)
|
1320/1700
|
Type
|
12.00R20
|
Cabin
|
Sleeper
|
none
|
OTHER
|
Engine horse power
|
290hp,330hp,340hp and 360hp,380hp
420hp is optional
|
Tyre
|
nylon,radial and tubeless is optional
|
ABS
|
optional
|
COLOR
|
optional
|
