Product name：High speed mini permanent magnet voice coil motor
Specifications
Motor model
|
VCMC100101A
|
VCMC30-25-0.5
|
VCMC40-20.0.5
|
VCMI1-035-6520-L0.5
|
PERFORMANCE PARAMETERS
|
Symbol
|
Units
|
|
Stroke
|
S
|
mm
|
10
|
25
|
20
|
20
|
Continuous Force (Tmax）
|
Fc
|
N
|
12
|
7
|
10
|
35
|
Peak Force
|
Fp
|
N
|
29.0
|
47.0
|
58.0
|
165.0
|
Motor Constant
|
Km25
|
N/Sqrt(W)
|
4
|
2
|
4
|
7
|
Max.Continuous Power Dissipation
|
Pc
|
W
|
8.7
|
15.6
|
7.3
|
27.6
|
Continuous Current
|
Ic
|
Arms
|
1.6
|
1.6
|
0.8
|
3.2
|
Peak Current (1S)
|
Ip
|
Arms
|
3.4
|
10.0
|
4.5
|
15.0
|
Force Constant (25℃，±5%）
|
Kf
|
N/Arms
|
9.0
|
4.7
|
12.9
|
11.0
|
Back EMF Constant (25℃，±5%）
|
Ke
|
Vrms/m/s
|
9.0
|
4.7
|
12.9
|
11.6
|
Electrical Resistance(25℃，±5%）P-P
|
R
|
Ω
|
4.8
|
6.1
|
12.3
|
2.7
|
Inductance(25℃，±20%）P-P
|
L
|
mH
|
3
|
2
|
5
|
3
|
Max Coil Temperature
|
Tmax
|
℃
|
120
|
120
|
120
|
120
|
Mover Mass
|
Mp
|
Kg
|
0.1
|
0.0
|
0.1
|
1.1
|
Stator Mass
|
Ms
|
Kg
|
0
|
0
|
0
|
0
|
Dimension
Advantages：
Simple structure, high precision, high efficiency, high response, maintenance-free, no cogging effect, no need for reversing, the repeated positioning accuracy of up to ±1µm, especially suitable for short stroke, fast response, high precision closed-loop servo control.
Mian application:
1. Vibration System: Shaking table, vibration platform.
2. Semiconductor industry: Wiring, cutting, drilling, welding etc.
3. Micro Machine industry: Feed systems, micro drilling, precision stamping.
4. Medical field: Micro-injection system, respiratory equipment, testing equipment.
5. Valve operation in the field: pressure test systems, pneumatic valve chemistry injection system.
