Products Detail:
The XSim DrMOS family is Fairchild's next-generationfully optimized, ultra-compact, integrated MOSFET plusdriver power stage solutions for high-current, high-frequency,synchronous buck DC-DC applications. TheFDMF6705 integrates a driver lC, two power MOSFETs.and a bootstrap Schottky diode into a thermallyenhanced, ultra-compact 6x6mm PQFN package
With an integrated approach,the complete switchingpower stage is optimized with regards to driver andMOSFET dynamic performance,system inductanceand Power MOSFET RS(ON.XST DrMOS usesFairchild's high-performance PowerTrench® MOSFETtechnology,which dramatically reduces switch ringing,eliminating the need for a snubber circuit in most buckconverter applications.
Benefits：
-Ultra-Compact 6x6mm PQFN, 72% Space-SavingCompared to Conventional Discrete Solutions
-Fully Optimized System Efficiency
-Clean Switching Waveforms with Minimal Ringing
-High-Current Handling
Features:
Over 93% Peak-Efficiency
High-Current Handling of 43A
High-Performance PQFN Copper Clip Package
3-State 5V PwM Input Driver
Shorter Propagation Delays than FDMF6704
Shorter Dead Times than FDMF6704Skip-Mode SMOD# (Low-Side Gate Turn Off) Input
Thermal Warning Flag for Over-TemperatureCondition
Driver Output Disable Function (DlSB# Pin)
Internal Pull-Up and Pull-Down for SOD# andDISB# Inputs, Respectively
