Honeywell 900U02-0100 I/O Modules
Each channel of the module can be soft configured as AI, AO, DI or DO. Features supported by UIO are:
• Channels soft configurable as AI, AO, DI or DO (All channel are sourcing type)
• SOE (Sequence of Events) with resolution of 1 mS (supported only in non-redundant UIO
configuration).
• Simplified wiring for SIL-2 applications due to single module solution
Note: The SIL-2 UIO has inbuilt advanced diagnostics such as, SIL certified microcontroller
and critical voltage monitoring. Due to its higher eliability, for SIL-2 UIO there is no need to do
2oo1 or 2oo3 for wiring of IOs for SIL-2 application.
• Line Monitoring for all configurations
• Short circuit protection for DO
• Per channel Safety Shutdown eliminates need for
external master relay
• *HART Supported
• * Single or Redundant Power Capability to Module
Contact Information!
Discuss pricing and delivery time with a sales representative
+86 189 6519 6563
sales17@amikon.cn
+86-189 6519 6563
Product Details
|
Module Number
|
900U02-0100
|
|
Dimension
|
144 x 145 x 35 mm
|
|
Weight
|
2104g
|
|
Item
|
4 I/O slot Rack1,2
|
|
Lead/Reserve indication
|
Green arrow LEDs
|
|
Mode Switch
|
Removable key ( 2 keys supplied)
|
|
Power Supply Loading
|
5V; 22mA max
|
