1. One-sentence pitch
The 942-M0A-2D-1G1-220S is Honeywell’s plug-in 8-channel redundant analog-input terminal block for Experion PKS C300; it swallows raw 4–20 mA signals, returns isolated digital data, and erases the need for separate barriers, marshalling racks or loop-power supplies.
2. Why it’s “Minimalist I/O”
l 3-way isolation (field ↔ system ↔ power) – no external isolators
l Back-plane redundancy built-in; no change-over relays
l Per-channel 24 V loop supply drives 2-wire transmitters directly
l Hot-swap during runtime – swap one FTA, keep the process alive
3. Certified performance
|
Parameter
|
Value
|
Note
|
|
Channels
|
8 AI
|
differential, individual A/D
|
|
Input range
|
0–22 mA
|
10 % over-range readable
|
|
Accuracy
|
±0.05 % F.S.
|
@ 25 °C, 36-month cal interval
|
|
Drift
|
0.002 %/°C
|
–40 … +70 °C
|
|
Isolation
|
1 500 Vrms
|
channel-channel-system
|
|
Loop power
|
24 V ±1 %
|
25 mA max per channel
|
|
Step response
|
50 ms
|
filter 10–500 ms adjustable
|
|
Field protection
|
short, reverse, surge ±1 kV
|
IEC 61000-4-5
|
|
Back-plane
|
redundant RJ-45 iFAT
|
switch-over <10 ms
|
|
Power draw
|
2.1 W fully loaded
|
fed from 24 V back-plane
|
4. Proven applications
Offshore skids: one FTA replaces eight isolators + eight fuse terminals, 3 kg weight saving
Fine chemicals: SIL1 temperature transmitters wired direct, TÜV certificate covers loop
Power auxiliaries: redundant carrier keeps AO signals bump-less, meets DL/T 774 code
5. Order & support
Ex-stock Xiamen, serial numbers verifiable on Honeywell portal.
Redundant carrier (942-D01-RX) and mounting clips available on the same PO.
