CC-PDOB01 51405043-175 | Digital Output Module
PLC Autocontroller | Sales Manager May | Wechat id: dcsfcs
monitoring and control module
Model CC-PDOB01, order number 51405043-175, is a "Digital Output (24 V DC bussed)" module in the Honeywell Series C I/O architecture.
This module provides 32 channels of digital outputs, designed in a "bussed-24 V DC" configuration, suitable for control systems to send on/off
signals to discrete field devices such as relays, valve actuators, and contactors. According to the Honeywell Series C I/O specification document,
the Digital Output module ("Digital Output – Bussed 24 VDC") features include all outputs sharing a single ground and electronic short-circuit protection.
Key Technical Specifications
n Module Model/Order Number: CC-PDOB01 / 51405043-175
n Output Channels: 32 channels (32 pt)
n Output Voltage Rating: 24 V DC (typical); Maximum load voltage approx. 30 V DC
n Isolation/Withstand Voltage: 1500 VAC RMS or ±1500 V DC Core Isolation Specifications
n On-State Voltage: 24 V (typical) at ~0.5 A load; Off-State Voltage: 0 V (maximum 3.3 V no load)
n Response Time: Maximum on/off switching time approx. 10 ms
n Protection Functions: Electronic short-circuit protection (fuse-less short-circuit proof); when a channel is short-circuited, the module detects and disconnects that channel without requiring fuse replacement.
Compatible modules and accessories
|
Same series of digital output modules
|
CC-PDOB11 / 51308373-175 etc.
|
Digital output modules for different specifications or redundant configurations within the same series.
|
|
Numeric input module
|
CC-PDIL01, CC-PDIL51 series
|
It is used in conjunction with the output module to acquire discrete input signals in the field.
|
|
Backplate/DIN rail mounting assembly
|
Series C I/O IOTA slots, busbars, terminal assemblies, etc.
|
This module requires installation with IOTA and a busbar rack, and must be connected to a field 24V DC bus power supply.
|
