HONEYWELL TC-IXR061 input module

PLC Autocontroller | 20 years of excellence in industrial automation parts supply

TC-IXR061|input module

PLC Autocontroller | Sales Manager May | Wechat id: dcsfcs

Product Identification

Model: TC-IXR061

Manufacturer:Honeywell

Type/Function: input module

TC-IXR061 input module

The TC-IXR061 is a 6-channel isolated RTD input module used by Honeywell in its Experion/C200 series control systems.

This module supports various RTD sensor types (platinum, nickel, copper) and resistance input ranges, providing high-precision

 measurement and open-circuit detection. Designed for long-term stable industrial operation, it is suitable for temperature monitoring

and control applications in harsh environments.

Key Technical Specifications

Model: TC-IXR061

Manufacturer: Honeywell

Module Type: 6-Channel Isolated RTD Input Module

Number of Channels: 6 galvanically isolated channels

Signal Input Range: 1–487Ω; 2–1000Ω; 4–2000Ω; 8–4020Ω

Resolution: 16 bits; typical 7.7mΩ/bit–60mΩ/bit (view range)

Accuracy: ±0.1%FS @ 25°C typical

Channel Bandwidth: DC to 15Hz (-3dB)

Module Update Rate: 50ms for all channels

Open Circuit Detection: Detection time <5 seconds, provides out-of-range readings

Common Mode Rejection: 120dB @ 60Hz; 100dB @ 50Hz

Normal Mode Noise Rejection: 60dB @ 60Hz

Product Advantages

High Precision and High Reliability: Supports multiple RTD input types, ±0.1%FS accuracy, 16-bit resolution, and excellent common-mode/positive-mode rejection characteristics, suitable for temperature measurement in harsh industrial processes.

Fast Response and Effective Monitoring: Short module update cycle (50ms) and supports open-circuit detection, enhancing the safety and reliability of process control systems.

Strong Anti-interference Design: Possesses excellent RFI immunity and multi-channel isolation design, effectively improving system stability.

Strong System Compatibility: Compatible with Honeywell's Experion/C200 series systems, facilitating maintenance of older systems and spare parts replacement, reducing system downtime risks.

More options

Power Module: TSXPSY2600 / TSXPSY5500: Provides 5V DC power

Input Module: TSXDEZ32D2K / TSXAEY1600: Digital and analog input

Output Module: TSXDSY16T2K / TSXASY4100: Digital and analog output

Communication Module: TSXETY4103 / TSXCPP110: Ethernet and communication expansion

Memory Card: TSXMRPC001M: Program and data storage expansion
