Dimension
|
5995*2495*3095mm
|
Approaching angle/Departure angle
|
16/40°
|
Overhang(front/rear)
|
1410/1085mm
|
Wheel base
|
3500mm
|
Max speed
|
110km/h
|
Curb weight
|
5800kg
|
Max towing weight
|
35870kg
|
Max loading on fifth wheel, Permitted(kg)
|
12070kg
|
Slope climbing capability
|
Max.40%
|
Engine
|
Model
|
WP10.340E32,water-cooled,4 Strokes 6 cylinders in line,turbocharged, directly injection
|
Displacement
|
9.726L/Diesel
|
Stroke
|
126/130mm
|
Max. power
|
213/2200 (kw/rpm)
|
Max.torque
|
1160/1200-1600(Nm/rpm)
|
Emission stantard
|
EuroⅢ
|
Fuel tanker capacity
|
400L
|
Clutch
|
#420, Single dry frictional disc,Hydraulic boosting
|
Gearbox
|
9JS119B, mechanism,9 forward gears,1 reverse gear, manual operated
|
Gear ratio of gear box
|
11.02/6.55/4.64/3.36/2.71/1.95/1.38/1.00/0.81 R: 11.52
|
Suspension system
|
Front
|
Non-free standing leaf spring,telescopic shock absorber with stablizer bar suspension , 9pcs
|
Rear
|
Non-free standing stablization spring, balance suspension system, 9+6pcs
|
Brake system
|
Service brake
|
Brake gap can be adjusted automatically, double circulation air brake system
|
Assistant brake
|
Engine exhaust brake
|
Park brake
|
Potential springs pressing on middle and rear wheels
|
Steering system
|
D50,whole circulation in ball, hydraulic booster
|
Frame
|
Fish belly shape, variable width, variable sections
|
Front axle (Mercedes Technology)
|
Double-shoe pneumatic brake, non-driving steering axle
|
Middle and Rear axle (Mercedes Technology)
|
Double-shoe pneumatic brake, ductile casting casing, with hub redactor, double reduction driving axle
|
Tyre
|
315/80R22.5
|
Electrical system
|
Battery
|
2X12V/135Ah
|
Generator
|
28V-35A
|
Starter
|
5.4Kw/24V
|
Cabin
|
NG80B Long-Flat roof cabin with single sleeper
Full steel skeleton structure, covered with double layer steel plate;
Can be tipped forwardly;
High back seat for driver;Electric lifting window ;
With inner A/C
|
