Specification of Carbon Nanotubes:
|
Part No.
|
Diameter
|
Length
|
Purity
(%)
|
SSA
(m2/g)
|
Bulk density
(g/cm3)
|
Color
|
|
SAT-MWNT-10U
|
3-15nm, 30-60nm
|
15-30um
|
90-99
|
250-270
|
0.06-0.09
|
black
|
Note: We can supply different size products of
Carbon Nanotubes powder according to client's requirements.
Stable quality; high purity; large specific surface area; high mechanical strength; superior conductivity; good thermal conductivity.
Application of Carbon Nanotubes:
1. MWCNTs are prepared by CVD.
2. MWCNTs can replace traditional conductive agents and are suitable for electrode materials such as LFP, LCO, LMN, NCM, graphite, etc., and the dosage is only 0.4%-0.8%.
3.MWCNTs can be widely used in various polymer materials, such as PE, PC, PA, PS, PP, PET, PEI, POM, PEEK, etc., to reduce surface resistance, permanent anti-static, improve cleanliness, improve surface quality, etc. It can meet various anti-static requirements of HDD industry, and is used in anti-static packaging of electronic industry, heat dissipation of electric vehicles and computers, electric guide wires, carrier tapes, conveyor belts, etc.
4. It can replace traditional plastic additives. The general dosage is only 0.1%-3%, which can achieve the ideal anti-static, enhanced, thermal conductivity and other properties.
SEM & XRD of Carbon Nanotubes:
Storage conditions:
Multi-walled Carbon Nanotube powder should be sealed and stored in a dry and cool environment. It should not be exposed to the air for a long time, to prevent agglomeration due to moisture, affecting the dispersion performance and use effect, and should avoid heavy pressure, do not contact with oxidant, and transport according to ordinary goods.
