HUAWEI OptiX OSN 9800 TN12HSC1 high power unidirectional optical supervisory channel board-- OSN9800 UPS
Product Description
The HSC1 board is mainly used to processes and regenerates one OSC optical supervisory signal in one directions.
Table 1 describes the functions and features of the HSC1 board.
Table 1 Functions and features of the HSC1 board
|
Function and Feature
|
Description
|
|
Basic function
|
Receives, processes, and transmits one OSC signal.
-
When containing 100 Gbit/s wavelength, the system supports transmission over a span of 48 dB attenuation.
-
When containing no 100 Gbit/s wavelength, the system supports transmission over a span of 53 dB attenuation.
|
|
Technical features
|
The OSC channel has no limitation on the distance between two optical line amplifiers (OLAs). The failure of an OLA does not affect the performance of the OSC channel.
The HSC1 board can be independent of the SCC board. If the SCC board is not in place, the HSC1 board transparently transmits the ECC channel contained in the OSC signal.
|
|
Regeneration function
|
Performs full 3R regeneration of the received OSC signal. At each site provisioned with an HSC1 board, the OSC signal can be correctly dropped and local monitoring and management information can be added to the OSC signal.
|
|
Operating wavelength of the OSC channel
|
The operating wavelength of the TN11HSC1 board is 1510 nm.
The operating wavelength of the TN12HSC1 board is 1511 nm.
|
|
Loopback
|
Inloop
|
Supported
|
|
Outloop
|
Supported
|
|
Optical-layer ASON
|
Supported
|
|
Parameter
|
Unit
|
Value
|
|
Signal rate
|
Mbit/s
|
4.096
|
|
Operating wavelength range
|
nm
|
1500 to 1520
|
|
Signal coding
|
-
|
CMI
|
|
Launched optical power
|
dBm
|
5 to 10
|
|
Receiver sensitivity
|
dBm
|
<= -48
|
|
Receiver overload
|
Product Details
Our Advantages
We have Huawei TN12HSC1 for sale, including refurbished and new ones, and the price is usually 90% lower than the original supplier's price. Our super fast turnaround time and high-quality inventory all over the world mean that we can accurately deliver the products replaced on the same day to the place where they are needed, and minimize network downtime.
Huawei TN12HSC1, like all our hardware, takes comprehensive warranty as the standard. Whether you need new products or renovated products, we only purchase green market equipment of the highest quality and environmental protection. All these are provided at the best possible price, and a large amount of cost-effectiveness will be directly passed on to you.
Huawei TN12HSC1 represents only one product in our world-class hardware portfolio. The portfolio includes very well-known industry names, such as Nokia, Huawei, ZTE, Siemens, Nortel, Ericsson, Alcatel, Lucent, etc. We have a lot of inventory, thank you very much for sharing with customers.
