HUAWEI OSN9800 U32 WDM Price Optical Transmitter Switching and Networking Equipment
Product Description
OptiX OSN 9800 Switching Platforms OSN9800 U16 U32 U64
|
Specifications
|
OptiX OSN 9800 U16
|
OptiX OSN 9800 U32
|
OptiX OSN 9800 U64
|
|
Dimensions (H x W x D)
|
847 mm x 442
mm x 295 mm
|
1,900 mm x 498
mm x 295 mm
|
2,200 mm x 600 mm x
600 mm (with cabinet)
|
|
Number of Service Slots
|
14
|
32
|
64
|
|
Switching Capability
|
5.6 Tbit/s universal
switching
|
12.8 Tbit/s universal
switching
|
25.6 Tbit/s universal
switching
|
|
Channel Spacing
|
50/100 GHz fixed grid for 40/80 wavelengths
|
|
37.5 GHz to 400 GHz flex grid
|
|
Rate per Channel (maximum)
|
100 GE, 200 GE, 400 GE, 1 TE, 2 TE
|
|
Wavelength Range
|
DWDM: 1,529.16 nm to 1,560.61 nm (C band, ITU-T G.694.1)
|
|
Power Supply
|
–48 V DC/–60 V DC
|
HUAWEI optix osn 9800 U32 WDM Price Optical Transmitter Switching and Networking Equipment
Flexible, large-capacity 10/40/100 GE Optical Switching and Networking (OSN) platform for building high-performance backbone and Metropolitan Area Networks. Total capacity up to 25.6 Tbit/s per fully configured system, scalable to over 100 Tbit/s with clustering. 400 GE per-slot capacity supports 100 GE transmission rates with ample capacity for long-haul transmission needs.
Integrated optical and electrical layer Automatically Switched Optical Network (ASON) support, Optical Transport Network (OTN), packet, and Generalized MPLS features are combined with energy-efficient electronics and advanced, dynamic cooling features to reduce OpEx costs.
Huawei’s OptiX OSN 9800 enables you to create reliable, large backbone and metropolitan networks with 40 to 100 GE transmission speeds over long distance
Product Details
Our Advantages
We have HUAWEI OSN9800 U32 for
sale, including refurbished and new ones, and the price is usually 90% lower
than the original supplier's price. Our super fast turnaround time and
high-quality inventory all over the world mean that we can accurately deliver
the products replaced on the same day to the place where they are needed, and
minimize network downtime.
HUAWEI OSN9800 U32, like all our hardware,
takes comprehensive warranty as the standard. Whether you need new products or
renovated products, we only purchase green market equipment of the highest
quality and environmental protection. All these are provided at the best
possible price, and a large amount of cost-effectiveness will be directly
passed on to you.
HUAWEI OSN9800 U32 represents only one product
in our world-class hardware portfolio. The portfolio includes very well-known
industry names, such as Nokia, Huawei, ZTE, Siemens, Nortel, Ericsson, Alcatel,
Lucent, etc. We have a lot of inventory, thank you very much for sharing with
customers.
