HWIC-3G-GSM Overview
The Cisco 3G-ANTM1919D antenna operates in the 806- to 960-MHz and 1710- to 2170-MHz frequency bands, and is designed for use with Cisco 3G wireless high speed WAN interface cards (HWICs). The Cisco 3G-ANTM1919D antenna is compatible with the Cisco 3G wireless WAN HWICs using a threaded Neill-Concelman (TNC) male connector with articulating joint.
HWIC-3G-GSM Specification
|
Product
Number
|
HWIC-3G-GSM
|
|
Product Description
|
3G
HSPA Wireless WAN HWIC supporting GPRS/EDGE/UMTS/HSDPA/HSUPA (Global SKU)
|
|
External interfaces
|
•
RJ-45 interface for use with third-party diagnostics and monitoring tools
• TNC RF port for antenna connection
• HWIC-3G-HSPA supports main and diversity antenna connector
|
|
Form factor
|
Single
wide Cisco 3G WWAN HWIC form factor
|
|
Physical dimensions (H x W x D)
|
0.75
x 3.08 x 4.9 in. (1.9 x 7.8 x 12.4 cm)
|
|
Weight
|
0.24
lb (3.84 oz)
|
|
Subscriber Identity Module (SIM) card
|
SIM
card socket; compliant with ISO-7816-2 (SIM mechanical)
|
|
Power
|
4.5W
maximum
|
|
Supported platforms
|
Modular
Cisco 1841, 1861, 1900, 2800, 2900, 3800 and 3900 Integrated Services Routers
|
|
|
|
