Fixed-point focus, select the focus point by touching any area on the screen for more precise focus response
Fast follow focus, zoom camera zoom process can be adjusted in real time lens focus, to ensure a clear and smooth picture
Starlight night vision, equipped with a starlight grade sensor equipped with super light-sensitive performance CMOS, low-light environment can also be obtained
real-time images in low-light conditions
HDR
The High Dynamic Range feature accurately captures highlights and dark details in a rendered dynamic scene, making the brightness and color of the image more realistic and natural, and better reproducing the details of the picture.
AI-enhanced intelligent identification tracking
Support optional tracking module, combined with self-developed AI algorithm technology, and collaborative control to achieve real-time follow and capture the target, and through real-time focus and zoom in order to highlight the selected object in the screen, the target will always be in the center of the screen and maintain a clear and visible picture ratio.
Support anti-lost tracking function, during the following process, if the target is blocked or briefly leaves the monitoring screen, when it enters the monitoring screen again, the A!tracking module can automatically recognize and continue to track.
parameters
|
size
|
121*101*78mm
|
|
weight
|
381g
|
|
working voltage
|
11~25.2V
|
|
working temperature
|
-10℃~50℃
|
|
power consumption
|
Average 4W, peak 12W
|
|
Lens optical zoom
|
10 times
|
|
Hybrid zoom lens
|
30 times
|
|
focal length
|
5.15±5%~47.38±5%mm
|
|
Minimum diagonal distance
|
200mm
|
|
Image sensor
|
1/2.7-inch CMOS with 4 million effective pixels
|
|
aperture
|
F1.8~2.5
|
|
FOV
|
1X optical zoom: diagonal 69.5 °, horizontal 61.5 °
|
|
|
10X optical zoom: 7.95 ° diagonally and 7 ° horizontally
|
|
TF card recording video resolution
|
2k（2560*1440）@30fps
|
|
Video storage rate
|
12Mbps
|
|
Support file system
|
FAT32/ex FAT
|
|
Photo file format
|
JPG
|
|
Video file format
|
H265
|
|
storage card type
|
Micro SD class10 supports up to 32GB
|
|
Photography mode
|
Single shot
|
|
Metering mode
|
evaluative metering
|
|
white balance
|
automatic
|
|
PTZ parameter
|
|
Angle jitter amount
|
±0.01°
|
|
Controllable pitch rotation range
|
-90°~25°
|
|
Controllable horizontal rotation range
|
-160°~160°
|
|
Roll rotation range
|
-30°~30°
|
|
The above parameters are for reference only. Detailed product parameters are subject to actual delivery
|
