Hyundai final drive bearings 39Q6-42120

39Q6-42120 bearings are used in the final drive Bearing system of HYUNDAI heavy machinery equipment:

39Q6-42120 HYUNDAI BEARING parts

Apply to  R250LC9, R250LC9A, R260LC9S, RB220LC9S, RB260LC9S, RD210-7, RD210-7V, RD220-7, RD220LC9











Hyundai excavator final drive bearing 39Q6-42120

P/N

39Q6-42120

Material:
GCR15
i/d mm
O/D
mm
H mm
Brand: ZHZB
Precision
P0 , P6 , P5
Structure:
Angular contact bearing

Product features:
1. Special bearing for excavator travel gearbox
2. High-strength high-quality steel
3. Smooth rotation and low noise
4. Compared with other companies' final drive bearings, the service life is increased by 50%

Our advantage:
100% factory quality inspection;
Minimum order quantity: 1;
Faster delivery efficiency;
Higher cost performance;
Have a mature production line so that we can customize according to the samples or drawings provided by customers;
A professional manufacturer of final drive bearings for excavators. Have many years of manufacturing experience

Production Process






Product Photos

39Q6-42120HYUNDAI 39Q6-42120Bearing 39Q6-42120



Any other parts for the final drive gearbox system you need , pls search from below picture and form list then mark to me , we will quote to you.

HYUNDAI PARTS



Pos.

Part No

Qty

Parts name

Comments

*.

@

[1]

  TRAVEL MOTOR ASSY

     SEE 4155

*-2.

39Q6-42100

[1]

  TRAVEL REDUCTION GEAR



*-2.

39Q6-42101

[1]

  TRAVEL REDUCTION GEAR



1.

39Q6-42110

[1]

  GEAR-RING



2.

39Q6-42120

[2]

  BEARING-ANG.BALL



3.

39Q6-42130

[2]

  SEAL ASSY-FLOATING



4.

39Q6-42140

[1]

  RING-NUT



5.

39Q6-42150

[1]

  PLATE-LOCK



6.

S017-120166

[4]

  BOLT-HEX



7.

39Q6-42160

[1]

  HOUSING



8.

S129-070206

[20]

  BOLT-SOCKET,UNIFIED



9.

39Q6-42170

[1]

  COUPLING



k10.

39Q6-42190

[1]

  CARRIER 2



k11.

39Q6-42200

[4]

  GEAR-PLANATARY 2



k12.

39Q6-42210

[4]

  BEARING-NEEDLE 2



k13.

39Q6-42220

[8]

  WASHER-THRUST 2



K14.

39Q6-42230

[4]

  PIN-CARRIER 2



K15.

S472-800164

[4]

  PIN-SPRING



K16.

39Q6-42350

[4]

  PIN-SOLID 2



17.

39Q6-42240

[1]

  GEAR-SUN 2



K18.

39Q6-42260

[1]

  CARRIER 1



K19.

39Q6-42270

[3]

  GEAR-PLANETARY 1



K20.

39Q6-42280

[3]

  BEARING-NEEDLE 1



K21.

39Q6-42290

[6]

  WASHER-THRUST 1



K22.

39Q6-42300

[3]

  PIN-CARRIER 1



K23.

S472-600364

[3]

  PIN-SPRING



24.

39Q6-42310

[1]

  GEAR-SUN 1



25.

39Q6-42320

[1]

  PLATE-THRUST



26.

39Q6-42330

[1]

  COVER



27.

S109-16110D

[24]

  BOLT-SOCKET



28.

P220-110205

[3]

  PLUG-HEX



29.

S602-035001

[1]

  RING-RETAINING



30.

39Q6-42341

[1]

  NAME PLATE



30.

39Q6-42342

[1]

  NAME PLATE



30.

39Q6-42342

[1]

  NAME PLATE



31.

39Q6-41800

[2]

  RIVET



32.

S631-024001

[3]

  O-RING



K.

39Q6-42250

[1]

  CARRIER ASSY KIT 1

     SEE ILLUST

K.

39Q6-42180

[1]

  CARRIER ASSY KIT 2

     SEE ILLUST

*-1.

@

[1]

  TRAVEL MOTOR UNIT

     SEE 4155

K.

39Q6-42250

[1]

  CARRIER ASSY KIT 1

     SEE ILLUST

K.

39Q6-42180

[1]

  CARRIER ASSY KIT 2
