Printer Parameters:

Items

Parameters

Printing Method

Thermal Line

Printing Width

48MM

Resolution

384dots/Line（8dots/mm，203dpi）

Printing Speed

130mm/Second

Interface Type

USB，COM，Internet（100M），WIFI，GPRS，Bluetooth

Print parameters

Line Spacing

3.75 mm（Can adjust line spacing by command）

Line No.

Font A:32 character /Line

Font B:42 character/Line

Simple,traditional Chinese-16 lines

Character

Standard GB18030 simplified / traditional Chinese Fonts

Character Size

ANKcharacter，Font A：1.5×3.0mm（12×24）

Font B：1.1×2.1mm（9×17） Simplified/Traditional Chinese：3.0×3.0mm

(24×24 Dots）

Bar code Character

Extended character set

PC437/Katakana/PC850/PC860/PC863/PC865/WestEurope/Greek/Hebrew

/EastEurope/Iran/WPC1252/PC866/PC852/PC858/IranII/Latvian/Arabic/PT151

,1251/PC737/WPC/1257/ThaiVietnam/PC864/PC1001/(Latvian)/(PC1001)/

(PT151,1251)/(WPC1257)/(PC864)/(Vietnam)/(Thai)

Bar code

1D bar code：UPC-A/UPC-E/JAN13(EAN13)/JAN8(EAN8)CODE39/ITF/

CODABAR/CODE93/CODE128

2D bar code：QRCODE

Graphics printing

Graphics printing

Supports bitmap download and print

Paper

Type

Thermal Roll

Width

57.5±0.5mm

Diameter

≤83mm

Feed Method

Easy feed(Clameshell feed)

Print commands

Commands

ESC/POS

Power

Power Adaptor

Input：AC 100V-240V,50-60Hz

Output：DC 12V/2A

Casher Drawer output

DC 12V/1A

Buffer

Input Buffer

4K

NV Flash

40K

physical characteristics

Weight

750g

Dimension

180*115*127(MM)

Environment

Working

Temp：5 ~ 45℃， Humidity：10 ~ 80%

Storage

Temp：-10 ~ 50℃ ，Humidity：10 ~ 90%（No dew）

Reliability parameter

Print Head Life

100KM（print density≤12.5）

Cutter Life

1000,000times
