ICS TRIPLEX T8310
TrustedTM Expander Processor-T8310
CONTACT: MIYA
JOB TITLE: MANAGER
Tel: 86-18020776792(Whats App )
QQ :2851195450
EMAIL：sales@amikon.cn
DESCRIPTION
The TrustedTM TMR Expander Processor module resides in the processor slots of the TrustedTM Expander Chassis and provides the ‘slave’ interface between the Expansion Bus and the Expander Chassis backplane. The Expander Bus allows multiple chassis systems to be implemented using UTP cable connections whilst maintaining the fault tolerant, high bandwidth Inter-Module Bus (IMB) capabilities. The module provides fault containment for the expander bus, the module itself and the expander chassis, ensuring that the effects of these potential faults are localised and system availability maximised. The module is fault tolerant with Hardware Implemented Fault Tolerant (HIFT), Triple Modular Redundant (TMR) architecture. Comprehensive diagnostics, monitoring and testing provide rapid fault identification. Hot standby and module spareing configurations are supported, allowing automatic and manual repair strategies.
FEATURES
-
Triple Modular Redundant (TMR), fault tolerant (3-2-0) operation
-
Hardware Implemented Fault Tolerant (HIFT) architecture
-
Dedicated hardware and software test regimes which provide fast fault recognition and response times
-
Automatic fault handling without nuisance alarming
-
Hot replacement
-
Front panel status LEDs
ELECTRICAL SPECIFICATION
Power Requirements 20 to 32V dc
Maximum Load 40W
Heat Dissipation 40W
Use with Chassis T8300
Module Clocks 50MHz
Expander Bus Data Rate 250Mbps
I/O Interface Expander Chassis backplane
Dimensions (HxWxD): 241mm x 30mm x 300mm (9.5ins x 1.2ins x 11.8ins)
Weight: 2.71kg (6lbs).
RELATED PRODUCTS ( in stock)
T8151B Trusted Communications Interface
T8153 Trusted Communication Interface Adapter
T8300 Trusted Expander Chassis
T8310 Trusted Expander Processor
T8311 Trusted Expander Interface
T8312 Trusted Expander Interface Adaptor Unit
T8270 24Vdc Fan Assembly, Rack Mounting
T8830 Trusted 40 channel Analogue Input FTA
T8800 Trusted 40 channel 24V dc Digital Input FTA
T8850 Trusted 40 channel Analogue or Digital Output FTA
T8200 Trusted Power Supply System
T8240 I/O Power Supply Chassis
T8231 Power Pack
T8293 Trusted Power Distribution Unit 15 Way Fuse
T8292 Trusted Power Distribution Unit MCB 24Vdc
T8290 Trusted Output Power Distribution Unit
T8449 Trusted Valve Monitor Module
T8444 Trusted TMR PGM Module
T8442 Trusted TMR Speed Monitor Module
T8314 Trusted Fibre TX RX Unit
T8297 Trusted Output Power Dist. Unit
T8296 Trusted Utilities Distribution Unit
T8271 Trusted Fan Tray 24Vdc Roof Mounted
T8173 Trusted Gateway Adaptor
T8170 Trusted Gateway Module
.....
Our products are new and original.
