Interlocking Plastic Grass Grid Parking

Grass Grid Parking in Leiyuan are with great permeable qualities. These plastic grass grids are made with voids on the pavers, which is where once installed, grass or vegetation is planted inside and allowed to grow through the pavers.


  • Press Strength180TONS/M2
  • Total Volume0.05CBM/BUNDLE
  • Size465x535x50mm
  • ColorBlack
  • MaterialHDPE

Interlocking Plastic Grass Grid Parking:

 Item Code  MZ-450A1
 Material  HDPE
 Size(L x W x H)  465x535x50mm
 Color  Black
 Compressive Strength  180ton/sqm
 Working Temperature  Dimensionally stable for -40℃ to 90
 Weight  1.15kg/pc
 Afforests Rate  95%~100%
 Porosity  90%
 Moisture Absorption  0.1%
 Environmental Compatibility  No toxic, harmless to plants, animals, microorganisms, inert material, groundwater neutral
 Anti HCL  According to GB4218-1984, 30%x24h, no visible change
 Anti NaOH  According to GB4218-1984, 40%x24h, no visible change
 Thermal Aging  According to GB/T 7141-1999, 70ICx24h, no visible change
 Anti UV  According to GB/T18830, UPE>30 T(UVA)AV<5%, qualified
 Packing  Bundle or Carton (or at your request)
 MOQ  100sqm
 Shipping

 About 20 days after receipt the deposit.

 FOB Xiamen, appointed shipping-terms and port accept.



Application:

  • Showgrounds

  • Car Parks

  • Storm water management

  • Handicap access routes

  • Golf buggy/trolley paths

  • Emergency vehicle access roads through fields

  • Modern factory building

  • Noble living communities

  • Truck maintenance and equipment yards

  • Construction entrance soil stabilization

Feature and Benefits:

  • 100% recycled plastics, eco-friendly grass grids
  • Flag plug type overlap joint, very convenient, arbitrarily adjust expansion joint width to fit temperature change
  • Perfect greening, provides more than 95% grass area
  • High compressive strength and durable, the plastic grass grids is permanent and long lasting
  • Fast and easy to install, maintenance with low cost
  • Permeability drainage performance, high water culvert
  • Anti-UV, resistance to acid and alkali corrosion, anti-wear and pressure
  • Grass grids has an open cell structure allowing unrestricted healthy grass root growth
  • Allows grass grid to grow with easy and binds firmly

100% recycled HDPE material, Leiyuan Grass Grid Parking are an interlocking celluar paving grid system for grass and ground reinforcement applications. Because of its chemically inert and non toxic feature, grass grid allow the drainage of stormwater back into the underground soil. Except for greening, the grass grid is also designed as a sustainable solution for areas of both heavy and light traffic. During installed, the grass grids can be filled with grass or gravel surface and allow full rainwater penetration.


Grass grids provides the pavement strength with the natural beauty of grass, at the same time, it eliminates soil compaction, reduces reflective heat and allowing for all weather accessibility at a very cost effective price.

Plastic Grass Grid Construction:

Leiyuan Plastic Grass Grid: High Strength, Long Life Service !


Reference

1. More Plastic Grass Paving Grid products, please refer: http://www.greengrassgrid.com/grass-grid_c5

2. More Porous Grass Pavers Installation, please refer: http://www.greengrassgrid.com/grass-grid-installation_n8

3. More Plastic Grass Grid FAQ, please refer: http://www.greengrassgrid.com/plastic-grass-grid-faq_n6

4. Learn more about Leiyuan Company, please refer: http://www.greengrassgrid.com/about-us_d1
