1. Function
It can be used in the traffic environmetns, such as bus stop, airport, part and so on as the guiding system. And it can also be used in banks, estate, stock to show the information of stock, exchange, estate and so on. Also, it is very popular in shops, gym, postoffice, hotel etc to show the important information.
2. Technology Character
(1) Adanced digital techonlody for vedio.
(2) Distributing scanning method and modularity in designs.
(3) Constant static driving method and the brightness can be adjusted by itself.
(4) Super brightness and pure pixels
(5) Clear pictures with distortion and doubble images.
(6) Can show vedio, cartoon, graph, letters, pictures and so on.
(7) Can be controlled by Lan remotely.
|
Item
|
PH5
|
|
Cabinet
|
Technology
|
SMD 3 in 1
|
|
Package Mode
|
2727
|
|
Pixel Pitch
|
5mm
|
|
Usage
|
outdoor
|
|
Module Size
|
160×320mm
|
|
Cabinet Size
|
640×640mm
|
|
Pixel Density
|
40000dots/m2
|
|
Color Configuration
|
1R1G1B
|
|
Cabinet Resolution
|
64×32dots
|
|
Main Specification
|
Best Viewing Distance
|
5~100m
|
|
Viewing Angle
|
horizontal ≥120°
vertical ≥120°
|
|
Temperature
|
-20°C~+60°C
|
|
Ave.Consumption
|
360 W/m2
|
|
Max.Consumption
|
850 W/m2
|
|
Control Mode
|
synchronism
|
|
Drive Mode
|
1/8 Scan
|
|
White Balance Brightness
|
≥1800cd/m2
|
|
Protection Level
|
IP65
|
|
Power Supply
|
220V/50Hz
|
|
MTBF
|
≥10000hours
|
|
Life Span
|
100, 000hours
|
|
Malfunction Dot Rate
|
