Performance Parameter

Light Source

Visible Laser diode ,650nm

Decode Capability

EAN-8,EAN-13,UPC-A,UPC-E,Code 39,Code 93,Code 128,EAN128,Codaber, Industoal 2 of 5,Interleave 2 of 5,Matrix 2 of 5,MSI,China Post Code and all 1D barcodes,etc.

Scanning Type

Single-line

Scan Rate

above 300 scans per second

Trigger Mode

Manual /Automatic inductive /Successive (Optional )

Yaw/Rotation/Pitch

65°/30°/55°

Precision

3&4mil(0.1mm)

Depth of scanning field

0-280mm（0.33mm.PCS 90%）

Error Rate

Less than 1/5million

Interface Support

USB-HID,USB-COM,PS2,RS232

Physical Parameter

Dimension

L173mm*W70mm*H68mm

Weight

170g

Housing Materials

ABS+PC

Cable Parameter

2M

Electrical Parameter

Voltage

DC 5V±10%

Current

85mA(Operating mode)

Environmental Parameter

Operating Temperature

-20℃~40℃

Storage Temperature

-40℃~70℃

Relative Humidity

5%~85%(Non-condensing)

Impact Resistance

withstands multiple 3m drops to concrete
