IPD90P04P405ATMA1 Infineon MOSFET
Parameter
| Manufacturer |
infineon |
| Product Category |
MOSFET |
| Mounting Style |
SMD/SMT |
| Technology |
Si
|
| Package / Case |
TO-252-3 |
Vds - Drain-Source Breakdown Voltage
|
40 V
|
Id - Continuous Drain Current
|
90 A
|
Rds On - Drain-Source Resistance
|
4.7 mOhms
|
Vgs - Gate-Source Voltage
|
- 20 V, + 20 V
|
Vgs th - Gate-Source Threshold Voltage
|
4 V
|
Minimum Operating Temperature
|
- 55 C
|
Maximum Operating Temperature
|
+ 175 C
|
Factory Pack Quantity
|
2500 |
Introduction
The IPD90P04P405ATMA1 offers a compact and efficient solution for power regulation, providing a maximum current rating of 90 A and a maximum voltage rating of 40 V. The MOSFET is designed to operate over a wide temperature range (-55°C to +175°C) and is highly reliable and robust.
The IPD90P04P405ATMA1 features a compact and robust TO-252 package, making it easy to mount on a printed circuit board. Additionally, the chip incorporates advanced features, such as low on-resistance and fast switching speeds, making it well-suited for use in a wide range of power management applications that require high efficiency and reliability.
Application
The IPD90P04P405ATMA1 is widely used in various industries, including automotive, industrial, and consumer electronics. As a power MOSFET, it is commonly used in power management applications, such as power supplies, motor control, and battery management. Its maximum current rating of 90 A and maximum voltage rating of 40 V make it an ideal component for regulating power in a wide range of electronic systems. Additionally, the chip's low on-resistance and fast switching speeds make it well-suited for use in high-efficiency power management applications. The IPD90P04P405ATMA1's ability to operate over a wide temperature range (-55°C to +175°C) and its highly reliable and robust design make it suitable for use in harsh environments. Overall, the IPD90P04P405ATMA1 is a versatile and reliable power MOSFET that can be used in a wide range of applications across different industries where efficient and reliable power management is crucial.
