System Architechture
Processor	Qualcomm quad-core 1.2GHz
Operating System	Android 7.0
Memory & Storage	1G RAM/8G Rom, micro-TF up to 128G
Display	4.5'' IPS super vision touch panel(540*960)
Battery	5600mAh,3.7V
Performance Parameter
Scan Engine	scandard 1D scanner or CCD scanner
Scan Density	4mil
Scan Speed	100 scans/sec
Scan Mode	continuous/trigger
Symbologies	EAN-8,EAN-13,UPC-A,UPC-E,Code 39,Code 93,Code 128,EAN128,Codaber, Industoal 2 of 5,Interleave 2 of 5,Matrix 2 of 5,MSI,etc.
Camera	8.0 megapixel
GPS	embedded GPS / AGPS
Mechanical
I/O ports	Micro USB
Charging Power	5V/2A
Wireless Connectivities
WWAN	GSM/GPRS/EDGE(850/900/1800/1900MHz),WCDMA(850/2100MHz)//
WLAN	ieee 802.00 a/b/g
Encryption	Web,WPA,WPA-PSK
Bluetooth	V4.0(compatible with 2.1+EDR)
Printer
Paper Width	58mm(roll diameter 30mm)
Resolution	384dots/line,90mm/s
Package
Size	152*77*29cm
Weight	500g
Box Size	152*77*29cm
Gross Weight	625g
