Products Name: Iron core linear motor stages (LM135 Series)
Characteristics:
• Long stroke, the maximum stroke reaches more than 4m
• Imported ACS, ELMO, Servotronix driver for optional
• The warranty period is 12 months since you receive the goods
• Production capacity 5000 Pieces permonth
• CE, RoHS and UL certification
Product Specifications
Motor Model/Parameter
|
|
Iron Core Linear Motor
|
|
Parameter\ Motor Model
|
Unit
|
FL21
|
FL31
|
FL41
|
FJ21
|
|
Continuous Force (Tmax）
|
N
|
118
|
176
|
236
|
125
|
|
Peak Force
|
N
|
314
|
466
|
628
|
498
|
|
Motor Constant
|
N//SqrtW
|
13.6
|
16.5
|
19.4
|
13.6
|
|
Max.Continuous Power Dissipation
|
W
|
75.2
|
114.2
|
147.8
|
84.2
|
|
Continuous Current (Tmax）
|
Arms
|
4
|
4
|
4
|
2.2
|
|
Peak Current (1S)
|
Arms
|
12
|
12
|
12
|
9
|
|
Force Constant (25℃，±5%）
|
N/Arms
|
29.5
|
44
|
59
|
56.8
|
|
Back EMF Constant (25℃，±5%）
|
Vrms/rad/s
|
9.8
|
14.7
|
19.7
|
18.8
|
|
Electrical Resistance(25℃，±5%）P-P
|
Ω
|
2.4
|
3.4
|
4.4
|
8.2
|
|
Inductance(25℃，±20%）P-P
|
mH
|
9.0
|
13.5
|
18.0
|
26
|
|
Max Coil Temperature
|
℃
|
120
|
120
|
120
|
120
|
|
Polar Distance (N-N) (360℃ Electrical cycle)
|
mm
|
20
|
20
|
20
|
20
|
|
Magnetic Attraction
|
KN
|
0.68
|
0.98
|
1.3
|
0.75
|
|
Mover Mass
|
Kg
|
1.6
|
2.3
|
3
|
1
|
Linear Motor Stages Selection
|
LM135-FL21-xxx-xxx-A
|
|
|
Parameter\ Stroke (mm)
|
100
|
200
|
300
|
400
|
500
|
600
|
700
|
800
|
900
|
1000
|
1100
|
1200
|
|
K
|
10
|
14
|
14
|
18
|
18
|
22
|
22
|
26
|
26
|
30
|
30
|
34
|
|
N
|
1
|
2
|
2
|
3
|
3
|
4
|
4
|
5
|
5
|
6
|
6
|
7
|
|
Stage Total Length (mm)
|
380
|
460
|
560
|
660
|
760
|
860
|
960
|
1060
|
1160
|
1260
|
1360
|
1460
|
|
Dowel Pin D1 (mm)
|
50
|
100
|
150
|
200
|
250
|
300
|
350
|
400
|
450
|
500
|
550
|
600
|
|
Stage Weight (kg)
|
8.7
|
10.1
|
11.5
|
12.8
|
14.2
|
15.7
|
16.9
|
18.4
|
19.8
|
21.1
|
22.5
|
24.0
|
|
Sliding Table M (mm)
|
170
|
|
A
|
8
|
|
B
|
3
|
|
Motion Parts Weight (kg)
|
3.6
|
|
LM135-FL31-xxx-xxx-A
|
|
|
Parameter\ Stroke (mm)
|
100
|
200
|
300
|
400
|
500
|
600
|
700
|
800
|
900
|
1000
|
1100
|
1200
|
|
K
|
10
|
14
|
14
|
18
|
18
|
22
|
22
|
26
|
26
|
30
|
30
|
34
|
|
N
|
2
|
2
|
2
|
3
|
3
|
4
|
4
|
5
|
5
|
6
|
6
|
7
|
|
Stage Total Length (mm)
|
430
|
530
|
630
|
730
|
830
|
930
|
1030
|
1130
|
1230
|
1330
|
1430
|
1530
|
|
Dowel Pin D1 (mm)
|
50
|
100
|
150
|
200
|
250
|
300
|
350
|
400
|
450
|
500
|
550
|
600
|
|
Stage Weight (kg)
|
10.7
|
12.2
|
13.6
|
14.9
|
16.3
|
17.8
|
19.0
|
20.5
|
21.9
|
23.2
|
24.7
|
26.1
|
|
Sliding Table M (mm)
|
240
|
|
A
|
12
|
|
B
|
5
|
|
Motion Parts Weight (kg)
|
4.7
|
|
LM135-FL41-xxx-xxx-A
|
|
|
Parameter\ Stroke (mm)
|
100
|
200
|
300
|
400
|
500
|
600
|
700
|
800
|
900
|
1000
|
1100
|
1200
|
|
K
|
14
|
14
|
18
|
18
|
22
|
22
|
26
|
26
|
30
|
30
|
34
|
34
|
|
N
|
2
|
2
|
3
|
3
|
4
|
4
|
5
|
5
|
6
|
6
|
7
|
7
|
|
Stage Total Length (mm)
|
500
|
600
|
700
|
800
|
900
|
1000
|
1100
|
1200
|
1300
|
1400
|
1500
|
1600
|
|
Dowel Pin D1 (mm)
|
50
|
100
|
150
|
200
|
250
|
300
|
350
|
400
|
450
|
500
|
550
|
600
|
|
Stage Weight (kg)
|
13.2
|
14.4
|
15.9
|
17.2
|
18.6
|
20.0
|
21.3
|
22.7
|
24.2
|
25.5
|
26.9
|
28.3
|
|
Sliding Table M (mm)
|
310
|
|
A
|
12
|
|
B
|
5
|
|
Motion Parts Weight (kg)
|
5.9
|
|
LM135-FJ21-xxx-xxx-A
|
|
|
Parameter\ Stroke (mm)
|
100
|
200
|
300
|
400
|
500
|
600
|
700
|
800
|
900
|
1000
|
1100
|
1200
|
|
K
|
10
|
14
|
14
|
18
|
18
|
22
|
22
|
26
|
26
|
30
|
30
|
34
|
|
N
|
1
|
2
|
2
|
3
|
3
|
4
|
4
|
5
|
5
|
6
|
6
|
7
|
|
Stage Total Length (mm)
|
380
|
480
|
580
|
680
|
780
|
880
|
980
|
1080
|
1180
|
1280
|
1380
|
1480
|
|
Dowel Pin D1 (mm)
|
50
|
100
|
150
|
200
|
250
|
300
|
350
|
400
|
450
|
500
|
550
|
600
|
|
Stage Weight (kg)
|
8.7
|
10.2
|
11.6
|
12.8
|
14.3
|
15.6
|
17.8
|
18.5
|
19.9
|
21.1
|
22.6
|
23.9
|
|
Sliding Table M (mm)
|
190
|
|
A
|
8
|
|
B
|
3
|
|
Motion Parts Weight (kg)
|
3.3
|
Kindly instruct us your requirements, you can provide below parameters to our engineer, free product manual and 3D model and a reasonable price will send to you anytime.
1. Effective stroke
2. Maximum speed
3. Maximum acceleration
4. Load
5. Repeatability accuracy
6. Straightness
7. Protectivefully sealed or semi-protected
Module several types:
Industry Applications:
Competitive motion stages, it is widely apply to heavy load, high acceleration, and high speed equipment.
Packaging & Delivery:
Packaging Details.: plywood packing
Price terms: FOB Shenzhen
Leading time: According to the order quantity, 5-7 days for sample order and 20 days for bulk order
