Feature:
◆Built in RFID module of INDY R2000
◆Multiple tags reading ability
◆High sensitivity to tag
◆Support 2 road infrared traps
◆Provide whistle and flashing light
◆Support SDK dynamic link libraries and secondary
development
Specification:
|
Item No.
|
JT-922
|
|
Performance
parameters
|
|
Working
Frequency
|
902~928 MHz or
865~868MHz
|
|
Protocol
|
ISO18000-6C(EPC
C1 GEN2)
|
|
Chip
|
Impinj R2000
|
|
RF
|
0～30dBm(Adjustable)
|
|
Software &
SDK
|
DEMO and C#, VC,
Java
|
|
Communication
port
|
RS232,TCP/IP OR RS232,WIFI
|
|
Reading range
|
3M(Depends on
antenna gain, tag & environment)
|
|
Storage space
|
1M or 8M Flash
save without power supply(Customized)
|
|
Real-time clock
|
without power
supply, real-time clock save and working(customized)
|
|
Frequency
modulation
|
hopping or fixed
frequency
|
|
RSSI
|
RSSI numerical
test
|
|
Antenna gain
|
12dBi circular
polarization
|
|
Working way
|
Buzzer & Red
flashing
|
|
Power
|
12V/3A Adaptor
|
|
Physical
parameters:
|
|
|
Item size
|
Height:1500mm,Screen:1450x600x90mm,Base:600x400x50mm
|
|
Net weight
|
38KG(Single
gate)
|
|
Shell material
|
Aluminum Alloy
|
|
Working
temperature
|
-20℃~+65℃
|
|
Storage
temperature
|
-45℃~+95℃
|
