Model

PT5060TSL

Driving Type

4x2    (Left hand drive)

Wheelbase

3360 mm

Overall Dimension

5715X2090X2523 mm

Cab

Forward control over engine, all-steel-welded construction

Sweeping System

Auxiliary engine

Isuzu tech engine

Stainless Steel Hopper Effective Volume

5 CBM

Stainless Steel Water Tank Volume (L)

1200

Sweeping Width (mm)

3000

Sweeping speed (km/h)

3~20

Sweeping Capacity (m2/h)

16500~82500

Blower rated rotation speed (rpm)

1800

Blower air capacity (m3/h)

8000

Blower air pressure (Pa)

7000

Side Brush Sweeping Brush Drive and Control

Electric control lever and switch control, Hydraulic driving

Engine

Model

4JB1CN

Type

Diesel, turbo charged inter-cooled, 4 cylinder

Max. Power

72 KW (98 HP)

Gearbox

MSB 5-shift, mechanical type, 5 forward and 1 reverse with

Tire

7.00-16

Color

Red    (Any color & logos up to wish)

Max Speed

100 km/h
