Color

Black

Print speed

200mm/sec(USB+Serial/Lan only)

300mm/sec(USB + Serial + Ethernet)

Paper width

79.5±0.5mm

Paper thickness

0.06~0.08mm

Print columns

576 dots per line or 512 dots per line

Resolution

203*203 dpi(Maximum)

Character size

 ANK, Font A: 1.5x3.0mm(12x24dots)

Font B: 1.1x2.1mm(9x17dots)

Simplified/traditional Chinese: 24x24 dots

Command

Compatible with ESC/POS

Interface

optional

(USB + Serial + Ethernet)/(USB+Serial)/(Ethernet only)

Bar code

UPC-A/UPC-E/JAN13(EAN13)/JAN8(EAN8)/CODABAR/ITF/CODE39/CODE93/CODE128

2D Bar code

QR CODE

Printing head

100 kilometers

Power supply

DC 24V==2.5A

Cash drawer

DC 24V==1A

Language

Multi-language

Dimension

183(D) x 143.5(W) x 135(H)mm

Net Weight

1.55 kg

Auto cutter

Automatic cutter
