Printing width
|
72mm
|
|
Column capacity
|
576 dots/line 512 dots/line
|
|
Printing speed
|
200mm/s
|
260mm/s
|
|
Interface
|
USB+Serial or USB+Ethernet
|
USB+Serial+Ethernet
|
|
Printing paper
|
79.5±0.5mm
|
|
Line spacing
|
3.75mm(adjustable by commands)
|
|
Weight
|
1.0kg
|
|
Dimension(D*W*H)
|
183*140*141.5mm
|
|
Printing
|
|
Printing Method
|
Direct thermal
|
|
Column capacity
|
576 dots/line 512 dots/line
|
|
Printing speed
|
200mm/s
|
260mm/s
|
|
Interface
|
USB+Serial/U+Lan
|
USB+Serial+LAN
|
|
Printing paper
|
79.5±0.5mm
|
|
Line spacing
|
3.75mm(adjustable by commands)
|
|
Cutter
|
|
Auto cutter
|
Partial
|
|
2D code
|
QR CODE/PDF 417
|
|
NV Flash
|
256k bytes
|
|
Power
|
|
Power adaptor
|
Input: AC 110V/220V, 50～60Hz
|
|
Power source
|
Output: DC 24V/2.5A
|
|
Cash drawer output
|
DC 24V/1A
|
|
Physical characteristics
|
|
Weight
|
1.0kg
|
|
Dimension(D*W*H)
|
183*140*141.5mm
|
|
Environmental Requirements
|
|
Working Environment
|
Temperature: 0-45℃,Humidity: 10-80%RH
|
|
Storage environment
|
Temperature: -10-60℃,Humidity: 10-90%RH
|
|
Reliability
|
|
Cutter life
|
1.5million cuts
|
|
Printer head life
|
100KM
|
