KNB-14 for KENWOOD also fits in the following models:
TCP-213 TK-2102 TK-2107
TK-260G TK-270 TK-272G
TK-278GC TK-3100K2 TK-3102
TK-3107 TK-360 TK-370
TK-372G
KNB-14 for KENWOOD can also replace the following batteries:
KNB-14H KNB-15A KNB-15S
KNB-20N KNB-14N
KNB-15B KNB-14A
KNB-15 KNB-15H KNB-20
|
General Specifications
|
|
Original Model No.
|
KNB-14
|
|
Compatible Radio Models
|
TK-378 TK-378GM TK-388 TK-2100 TK-2102A TK-238 TK-260GE TK-270G TK-278 TK-278GM TK-3101 TK-3102A
|
|
Place Of Original
|
China
|
|
Voltage/Type
|
7.2V/7.4V LI-ION NI-CD NI-MH
|
|
Capacity
|
900/1100/1300/1500 mAh
|
|
Dimensions (mm)
|
112(W)*61(D)*18(H)
|
|
Mechanical
|
|
Cells used
|
Chinese cell or Japan cell
|
|
Plastic material
|
PC+ABS+fireproofing material
|
|
Assembly construction
|
Housings bonded by ultrasonic
|
|
Charger&radio contacts
|
silver-plate
|
|
Environmental
|
|
Charging temperature
|
+0°C to +45°C
|
|
Discharging temperature
|
-20°C to +60°C
|
|
Storage temperature
|
+25°C + –5°C
|
|
Storage position
|
non-critical
|
|
Package
|
|
Inner packing
|
Polyethylene tape packaged batteries in white separate boxes
|
|
Outer packing
|
Put white separate boxes into
34*34*34cm carton, 100PCS each carton
|
